Supermicro Sys-740Gp-Tnrt Server Tower (4U) Intel® Xeon® 3000 Sequence 2200 W Ddr4-Sdram

Supermicro Sys-740Gp-Tnrt Server Tower (4U) Intel® Xeon® 3000 Sequence 2200 W Ddr4-Sdram

SKU:SYS-740GP-TNRT

$4,466.57
$4,466.57
Sale Sold out
Shipping calculated at checkout.
          View full details
          Description
          Specifications
          Reviews, Que. & Ans.

          Description :

          Dual Socket P+ (LGA-4189) 3rd Gen Intel Xeon Scalable Processors, Intel C621A Chipset, 16 DIMM Slots, 3200/2933/2666 ECC DDR4 LRDIMM; RDIMM; Intel Optane Persistent Memory 200 series, 2 M.2 NVMe or SATA Supported Total 8x 3.5" Hot-swap drive bays Up to 8 NVMe drives, 2x 2200W redundant Titanium level power supplies

          Supermicro SYS-740GP-TNRT. Processor family: Intel® Xeon® 3000 Sequence. Internal memory type: DDR4-SDRAM. Ethernet LAN. Power supply: 2200 W, Redundant power supply (RPS) support. Chassis type: Tower (4U)

          Specifications :

          General Information

          Manufacturer Supermicro Computer, Inc
          Manufacturer Part Number SYS-740GP-TNRT
          Manufacturer Website Address http://www.supermicro.com
          Brand Name Supermicro
          Product Line SuperServer
          Product Model 740GP-TNRT
          Product Name SuperServer SYS-740GP-TNRT (black)
          Product Type Barebone System
          UPC 0672042424016

          Chipset

          Chipset ManufacturerIntel
          Graphics Controller ManufacturerASPEED
          Graphics Controller ModelAST2600
          Ethernet TechnologyGigabit Ethernet

          Power Description

          Maximum Power Supply Wattage2200 W
          Product ColorBlack
          Height18.1"
          Width7"
          Depth26.5"
          Weight (Approximate)52.91 lb

          Miscellaneous

          Package Contents
          • SuperServer SYS-740GP-TNRT (black)
          • 1 x Super X12DPG-QT Motherboard
          • 1 x Full-Tower Chassis
          • 1 x 8-port 3.5" HDD/NVMe backplane for 4U Tower chassis, all 8 ports support NVMe Gen4 / SAS / SATA devices.,RoHS
          • 2 x PWCD,US/EU/Canada/China/Australia,IEC60320 C14 TO C13,4FT,17
          • 4 x PWYCB,GPU,2x4M/CPU to two (2x3F+2x1F)/PCIe,P4.2, 5CM,16/20AW
          • 2 x Slimline x4 (LE) to Slimline x4 (STR),INT,30CM,100 OHM,
          • 2 x Slimline x8 (LE) to Slimline x8 (RE),INT,30CM,85 OHm,R
          • 4 x NVMe Panetone 159C on Latch
          • 1 x STD I/O Shield for X12DPG-QT with EMI Gasket
          • 2 x 4U Active CPU Heat Sink for X12 Generation DP Workstations and 4U Servers
          • 2 x 1U 2200W Redundant, Titanium, 76(W) X 40(H) X 336(L) mm
          • 1 x Power Distributor Board is for 4U GPU solution using regular
          • 1 x ROUND 16 TO 16 PIN RIBBON FP CABLE 30"L, LF
          • 2 x US POWER CORD 16AWG, PB FREE
          • 4 x 4 TO 4 PIN FAN POWER CABLE, 210MM
          • 2 x 4 TO 4 PIN REAR FAN PWR EXT W/ SQUARE HEADER, 30CM (PWM)
          • 2 x 80x80x38 mm 4-pin PWM Fan Assembly for SC743, SC745
          • 2 x 92x38mm 4-PIN PWM FAN W/ HUS for SC747
          • 2 x 92x92x38 mm, 7.5K RPM, SC747 Middle Fan for Passive Cooling GPU
          • 1 x SC747 plastic front bezel
          • 3 x Black 5.25 drive tray w/o rail (SC747)
          • 8 x Black gen 6.5 hot-swap 3.5 inch HDD Tray
          • 1 x SC747BTQ-R2K04B Front Control Panel PCB (2x USB3.0, Audio)
          • 1 x Black plastic top cover for SC747
          • 1 x GPU Card Holder (11 slots) for SC747TQ, SC842
          • 1 x fixed 3.5" dummy cover for SC747
          • 1 xPlastic feet (2 pcs/set) for 4U tower chassis, black color

          Warranty

          Limited Warranty3 Year
