Mfr Part Number: SYS-1026GT-TRF
-
Motherboard: X8DTG-QF+
-
Processor: Dual LGA1366
- Support Intel 64-bit Xeon X5600/E5600/L5600 Series Processors (Westmere), 40W - 130W
- Support Intel 64-bit Xeon X5500/E5500/L5500 Series Processors (Nehalem-EP), 38W - 95W
- QPI up to 6.4 GT/s
-
Chipset: North Bridge Intel 5520 (Tylersburg) & South Bridge PLX 8647 + ICH10R
-
Memory: 6x 240pin DDR3-1333/1066/800 DIMM Slots, Supports up to 96GB ECC/REG Memory
-
Slots: 4x PCI-Express 2.0 x16 Slots (one runs at x8 & is a low-profile slot via riser card)
-
SATA: 6x SATA2 Ports, Supports RAID 0, 1, 5, 10
-
Video: Matrox G200eW Graphics w/ 16 MB DDR2 Video Memory
-
LAN: Intel 82576 Dual-Port Gigabit Ethernet Controller; 1x Realtek RTL8201N PHY (dedicated IPMI)
-
Drive Bays: 4x 2.5" SATA Hot-swap Drive Trays
-
Backplane: SAS / SATA HDD Backplane (SAS support requires optional SAS controller)
-
Ports: 2x USB 2.0 Ports, 1x VGA Port, 1x Serial Port, 2x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
-
Form Factor: 1U Rackmount
-
Power Supply: 1800W 80 Plus Platinum Certified (1+1) Redundant Power Supply w/ PMBus
-
System Cooling: 10x 4cm Heavy-duty Counter-rotating Fans w/ Optimal Fan Speed Control
-
Front Panel:
-
Buttons: Power On/Off, System Reset
-
LEDs: Power, HDD Activity, 2x Network Activity, System Overheat/ Fan Fail/ UID
-
Color: Black
-
Dimensions (WxDxH): 17.2 x 30.6 x 1.7 inch / 437.0 x 777.0 x 43.0 mm
-
Gross Weight: 37.0 lbs / 16.78 kg
- RoHS Compliant
