Supermicro Superchassis 823Mtqc-R802Lpb Rack Black 800 W

Supermicro Superchassis 823Mtqc-R802Lpb Rack Black 800 W

SKU:CSE-823MTQC-R802LPB

$972.92
$972.92
Sale Sold out
Shipping calculated at checkout.
          View full details
          Description
          Specifications
          Reviews, Que. & Ans.

          Description :

          2U, 800W, 3x 3.5" hot-swap SAS/SATA, max. MB EE-ATX

          Supermicro SuperChassis 823MTQC-R802LPB. Form factor: Rack, Type: Server, Product colour: Black. Power supply: 800 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Supported HDD sizes: 3.5". Width: 437 mm, Depth: 450 mm, Height: 89 mm. Package width: 594 mm, Package depth: 826 mm, Package height: 251 mm

          Specifications :

          General Information

          Manufacturer Supermicro Computer, Inc
          Manufacturer Part Number CSE-823MTQC-R802LPB
          Manufacturer Website Address http://www.supermicro.com
          Brand Name Supermicro
          Product Line SuperChassis
          Product Model 823MTQC-R802LPB
          Product Name SuperChassis 823MTQC-R802LPB
          Product Type Computer Case
          UPC 0672042291571
          Product ColorBlack
          Height3.5"
          Width17.2"
          Depth17.7"

          Miscellaneous

          Package Contents
          • SuperChassis 823MTQC-R802LPB
          • 1 x SC823M Intel DP X10 Universal Mylar Air Shroud, 12x13MB
          • 1 x 3-port SC825M SAS3 12Gbps TQ backplane, support up to 3x 3.5-inch SAS3/SATA3 HDD/SSD
          • 1 x ROUND 16 pin TO 16 PIN RIBBON FP CABLE 75cm. 28AWG
          • 2 x NEMA5-15P to C13 US power cord 16AWG 6ft, PBF (default for high watt)
          • 1 x Black DVD and USB dummy cover for SC823M
          • 4 x 40x40x56 mm 13K-11K RPM Counter-rotating Fan w/ a 160-mm Wire Coming out from the Fan Inlet Side,RoHS/REACH
          • 1 x Fan Tray for Six 4056 Fans
          • 2 x Dummy fan 40x56mm for 40x56 counter-rotating fan (cost-effective)
          • 3 x Black gen 5.5 hot-swap 3.5"; HDD tray
          • 1 x HDD cage housing 3 trays for SC823M
          • 1 x SC823M 24PIN REDUNDANT POWER DISTRIBUTOR
          • 2 x 1U 800W 90-264VAC/47-63Hz, and wide DC input 180Vdc~300Vdc
          • 1 x Rail set, quick/quick, default for 2,3U 17.2";W
          • 1 x Front I/O window for SC823M LP
          • 1 x SC823M rear window

          Warranty

          Limited Warranty3 Year
