Name: Supermicro Mbd-H12Ssl-Nt-O Socket Sp3/ Single Amd Epyc 7002/ Ddr4/ Sata3&Usb3.0/ M.2/ Atx Server Motherboard, Retail
Brand: Supermicro
SKU: MBD-H12SSL-NT-O
Price: 935.34 USD
Availability: InStock

Supermicro Mbd-H12Ssl-Nt-O Socket Sp3/ Single Amd Epyc 7002/ Ddr4/ Sata3&Usb3.0/ M.2/ Atx Server Motherboard, Retail

Roll over image to zoom in Click on image to zoom

Mfr Part Number: MBD-H12SSL-NT-O
Processor:
- CPU: Single AMD EPYC 7002 Series Processor; Socket SP3
- Cores: Up to 64 Cores
- Chipset: System on Chip
System Memory:
- Memory Capacity: 8 DIMM slots; Supports up to 2TB Registered ECC DDR4 3200MHz SDRAM; 8-channel memory bus
- Memory Type: DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs
- DIMM Sizes: 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
- Memory Voltage: 1.2V
- Error Detection: Corrects single-bit errors; Detects double-bit errors (using ECC memory)
On-Board Devices
- SATA: SATA3 (6 Gbps)
- IPMI: Support for Intelligent Platform Management Interface v. 2.0; IPMI 2.0 with virtual media over LAN and KVM-over-LAN support; ASPEED AST2500 BMC
- Network Controllers: Dual 10GBase-T LAN via Broadcom BCM57416; 1 Realtek RTL8211F PHY (dedicated IPMI)
- VGA: ASPEED AST2500 BMC
Input/ Output:
- SATA/NVMe Hybrid: 2 SlimSAS x8 (each: 8 SATA3 or 2 NVMe)
- LAN: Dual 10GBase-T LAN ports; 1 RJ45 Dedicated IPMI LAN port
- USB: 6 USB 3.0 ports (4 rear + 2 via header)
- VGA: 1 VGA port
- Others: 1 COM port (rear); TPM 2.0 header
Expansion Slots:
- PCI-Express: 5 PCI-E 4.0 x16; 2 PCI-E 4.0 x8
- M.2: Interface: 2 PCI-E 4.0 x4; Form factor: 2280, 22110; Key: M-key
Chassis (Optimized for H12SSL-NT):
- 1U: SC813MFTQC-R407CB
- 2U: SC213AC-R1K23LPB; SC216BE1C4-R1K23LPB; SC826BE1C4-R1K23LPB
- 3U: SC836BE1C-R1K23B
- 4U: SC846BE1C-R1K23B
System BIOS:
- BIOS Type: AMI 256Mb SPI Flash EEPROM
- BIOS Features: Plug and Play (PnP); DMI 2.3; PCI 2.2; ACPI 5.1; USB Keyboard Support; SMBIOS 3.1.1
Management:
- Software: Super Doctor 5; Watch Dog; NMI; SUM; IPMI 2.0, KVM with dedicated LAN
- Power Configurations: ACPI Power Management; Power-on mode control for AC power loss recovery
PC Health Monitoring
- CPU: Monitors CPU Core Voltages, +3.3V, +5V, +5V standby, +3.3V standby; CPU switching voltage regulator; Supports system management utility; VBAT
- FAN: Up to 7-fan status tachometer monitoring; Up to 7 4-pin fan headers; Dual Cooling Zone; Status monitor for speed control; Pulse Width Modulated (PWM) fan connectors
- Temperature: Monitoring for CPU and chassis environment; CPU Thermal Trip Support; Thermal control for 7x Fan connectors; IC Temperature Sensing Logic
- LED: CPU/ System Overheat LED
- Other Features: Chassis Intrusion Detection; Chassis Intrusion Header; UID
Environmental Specifications
- Operating Temperature: 10C to 35C (50F to 95F)
- Non-operating Temperature: -40C to 70C (-40F to 158F)
- Operating Relative Humidity: 8% to 90% (non-condensing)
- Non-operating Relative Humidity: 5% to 95% (non-condensing)
Form Factor: ATX
Dimensions: 12" x 9.6" (30.5cm x 24.4cm)
*All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country. All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers.

General Information

Manufacturer	Supermicro Computer, Inc
Manufacturer Part Number	MBD-H12SSL-NT-O
Manufacturer Website Address	http://www.supermicro.com
Brand Name	Supermicro
Product Model	H12SSL-NT
Product Name	H12SSL-NT Server Motherboard
Product Type	Server Motherboard
UPC	672042423361

Chipset

Chipset Manufacturer	AMD

Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2500

Total Number of USB Ports	4

Width	12"
Depth	9.6"

Miscellaneous

Package Contents	H12SSL-NT Server Motherboard 6 x I/O Cable 1 x I/O Shield

Warranty

Limited Warranty	1 Year
