Name: Qnap Ts-H1283Xu-Rp-E2236-128G-Us Intel Xeon E-2236 3.4Ghz 128Gb Ddr4 12-Bay 2U Rackmount Quts Hero Nas
Brand: QNAP
SKU: TS-H1283XU-RP-E2236-128G-US
Price: 6001.95 USD
Availability: InStock

Qnap Ts-H1283Xu-Rp-E2236-128G-Us Intel Xeon E-2236 3.4Ghz 128Gb Ddr4 12-Bay 2U Rackmount Quts Hero Nas

Roll over image to zoom in Click on image to zoom

Mfr Part Number:TS-H1283XU-RP-E2236-128G-US
Hardware:
- CPU:Intel Xeon E-2236 6-core/12-thread 3.4 GHz processor (burst up to 4.8 GHz)
- CPU Architecture:64-bit x86
- Floating Point Unit:Yes
- Encryption Engine:Yes(AES-NI)
- System Memory:128 GB UDIMM DDR4 ECC (4 x 32GB)
- Maximum Memory:128 GB (4 x 32 GB)
- Memory Slot: 4 x Long-DIMM DDR4
- Flash Memory:5GB (Dual boot OS protection)
- Drive Bay:12 x 3.5-inch SATA 6Gb/s, 3Gb/s
- Drive Compatibility:3.5-inch SATA hard disk drives, 2.5-inch SATA hard disk drives, 2.5-inch SATA solid state drives
- Hot-swappable:Yes
- SSD Cache Acceleration Support:Yes
- LAN Port:
  - 4x Gigabit Ethernet Port (RJ45)
  - 10 Gigabit Ethernet Port: 2 x 10GbE SFP+ SmartNIC port, 2 x 10GBase-T port
- Wake on LAN (WOL):Yes
- Jumbo Frame:Yes
- PCIe Slot: 4

  - Slot 1: PCIe Gen 2 x4 (PCH)

  - Slot 2: PCIe Gen 3 x8 (CPU)

  - Slot 3: PCIe Gen 3 x4 (CPU)

  - Slot 4: PCIe Gen 3 x4 (CPU)
- USB 3.2 Gen 2 (10Gbps) Port:
  - 2 x Type-C USB 3.2 Gen 2 10Gbps
  - 4 x Type-A USB 3.2 Gen 2 10Gbps
- LED Indicators: HDD 1-12, Status, LAN, storage expansion port status
- Buttons:Power, Reset
- Operating temperature:0 - 40 C (32F - 104F)
- Storage Temperature:-20 - 70C (-4F - 158F)
- Relative Humidity:5-95% RH non-condensing, wet bulb: 27C (80.6F)
- Sound Level:40.6 db(A)
- System Warning:Buzzer
- Max. Number of Concurrent Connections (CIFS) - with Max. Memory:10000
Operating System:QuTS hero 4.5.0 (embedded Linux)
Supported File Systems:
- Internal hard drive (ZFS)
- External hard drive (EXT3, EXT4, NTFS, FAT32, HFS+, and exFAT)
Network & Virtual Switch:
- TCP/IP: Dual stack (IPv4 and IPv6)
- Jumbo frame
- DHCP server and client
- RADVD
- USB Wi-Fi adapter
- Static Route
- NCSI (Network Connectivity Status Indicator)
- DDNS settings (Customize & Multiple Service )
- Port trunking (Link aggregation, supports 7 modes)
  - failover
  - Load balancing
- Virtual switch
  - Network Address Translation (NAT)
  - Spanning Tree Protocol (STP)
  -Thunderbolt to Ethernet converter (T2E)
  - Software-Defined Switch mode
Security:
- Network access protection with auto-blocking (SSH, Telnet, HTTP(S), FTP, CIFS/SMB, and AFP)
- Host access control for shared folders (CIFS/SMB)
- AES 256-bit folder-based encryptions which are validated by FIPS 140-2 CAVP (Cryptographic Algorithm Validation Program)
- 256-bit external drive encryption (AES)
- Importing of SSL certificates from Lets Encrypt
- Instant alerts through email, SMS, push service, audio, and LCD panel
- 2-step verification
Storage Management:
- RAID Hot Spare and Global Hot Spare
- RAID Rebuild Speed Customization
- Pool Over-provisioning
- SSD TRIM
- Disk auto S.M.A.R.T. data migration
- Disk bad block scan and S.M.A.R.T test.
- Disk bad block recovery
- Disk secure data erase
- Ironwolf Health Management
- Checksum for end-to-end data integrity
- Silence error detection and self-healing
- Pool scrub for data verification
- Share folder quota management
- Online share expansion
- Share type conversion
- Share shrink
- Inline deduplication for shared folder/LUN
- Inline compression for shared folder/LUN
- WORM (Write Once Read Many) for shared folder
- Storage expansion using QNAP expansion units
- JBOD enclosure roaming
- SSD read-only cache
- SSD read cache and write log
- Supported RAID types
  - Storage pool with RAID 0, 1, 5, 6, 10, 50, 60, Triple Parity, Triple Mirror
- Storage pools
  - The maximum single storage pool size is 1 PB
  - The maximum storage pool number is 128
- Storage space utilization
  - The maximum single shared folder/ LUN capacity is 1 PB
  - The maximum shared folder number is 256
- Snapshots: The maximum number of snapshots varies depending on installed memory

  - Share and LUN snapshots

  - Snapshot Dashboard

  - Snapshot Manager

  - Snapshot local restore and revert

  - Snapshot Clone

  - Snapshot Replica and Snapshot Vault

  - Snapshot remote restore and revert

  - Unified Snapshot Directory

  - Support for Windows Previous Versions (CIFS/SMB)

  - Snapshot Agent for Microsoft Windows and VMware vSphere

  - The maximum number of system snapshots is 65,536

  - The minimum Snapshot Interval is 1 min
Form Factor:2U Rackmount
Power Supply Unit:500W(x2), 100-240V
Power Consumption -Operating Mode, Typical:105.12 W
Fan:System fan: 2 x 60mm, 12VDC
Dimensions (HxWxD):3.48 18.98 22.13 inch
Weight (Net):25.9 lbs
