Advantech 8-port RS-232/422/485 PCI Express Communication Card PCIE-1622B-BE

Description :

Advantech 8-port RS-232/422/485 PCI Express Communication Card

PCIE-1620 is an 8-port RS-232, and PCIE-1622 is an 8-port RS-232/422/485 PCI Express communication cards that are compatible with the PCI Express x 1 specification. The cards provide eight EFT protected RS-232/422/485 ports up to 2,500 VDC, and have many functions such as high transmission speed of 921.6 kbps; either eight independent RS-232 ports or eight independent RS-232/422/485 ports which comes with high-performance PCIe958 UARTs with 128-byte FIFO to reduce CPU load. Thus, the PCIE-1620/ PCIE-1622 are especially suitable for making your system reliable in multitasking environments.

• 8 x RS-232 or RS-232/422/485 ports


• XR17V358 UART with 256-byte FIFOs


• Supports any baud rate setting


• PCI Express bus 2.0 compliant


• Speeds up to 921.6 kbps for extremely fast data transmission

Product Type: Multiport Serial Adapter
Environmentally Friendly: Yes
Environmental Certification: RoHS
Country Of Origin: Taiwan
Brand Name: Advantech
Form Factor: Plug-in Card
Manufacturer: Advantech Co., Ltd
Product Name: 8-port RS-232/422/485 PCI Express Communication Card
Manufacturer Part Number: PCIE-1622B-BE
Manufacturer Website Address: http://www.advantech.com
Limited Warranty: 5 Year
