Mfr Part Number: Q82M
-
Features:
- Multi-platform Compatible
- Ultra quiet 80 mm fluid dynamic bearing PWM fan with low noise impeller
- Optimized heatsink design for efficient heat dissipation
- Easy installation with push pins without mainboard disassembly
-
CPU Compatibility:
-
Intel: LGA1156/ 1155/ 1151/ 1150/ 775
-
AMD: AM4/ AM3+/ AM3/ AM2+/ AM2/ FM2+/ FM2/ FM1
-
TDP: 66W
-
Heatsink Material: Aluminum
-
Heat Base Material: 36 x 41mm Aluminum
-
Heat Pipes: N/A
-
Surface Treatment: Anti-oxidation Protective Layer
-
RGB Version: N/A
-
Included Fans: 1pcs
-
Fan Speed: 800~180010%RPM
-
Air Flow: 30.0CFM (Max)
-
Static Pressure: 1.95mmH20(Max)
-
Noise Level: 18.0 dBA
-
Rated Voltage: 12VDC
-
Operating Voltage: 8~13.2VDC
-
Started Voltage: 7.5VDC
-
Rated Current: 0.18 A (Fan Moto)
-
Power Input: 2.2 W
-
Bearing Type: Hydraulic Bearing
-
Fan Dimensions: 80.0 x 80.0 x 25.0 mm
-
Dimensions (WxLxH): 85.0 x 125.0 x 74.0 mm (Overall)
-
Weight/Loading: 190.0 g
