Mfr Part Number: SL120-3B
-
Bulletpoints :
- Controller Supports up to 16 UNI FAN
- Unprecedented flexibility / A quicker and easier installation process
- Daisy-Chain Design : Slide-in / PIN-to-PIN interlocking mechanism
- L-CONNECT Software (Intuitive Control Interface)
- Multiple effect /Ability to sync 32 LEDs per fan
- High static pressure / quiet operation
- Premium quality / sandblasted aluminum parts / Aluminium frame
-
Rated Voltage: DC 12V(FAN) & 5V(LED)
-
Color: Black
-
Fan Speed: 800~1900RPM
-
Max. Air Pressure: 2.54mmH2O
-
Max. Air Flow: 58.54CFM
-
Acoustical Noise (Min-Max.): 17dB ~ 31dB
-
Locked Current: >= 0.5mA
-
Bearing Type: Fluid Dynamic Bearing(FDB)
-
Operation Voltage: DC 12V & 5V
-
Start-up Voltage: DC 6.0V
-
Input Current: 0.18A(FAN) / 0.6A (LED)
-
Input Power: 3.6W
-
Dimension: 122.8x122.4x25mm
