Fixed Depth Rack - 22U, 4-Post, 20.6"W X 29"D, M6 Mounting, 2200-Lb. Capacity, G

Description :

Black Box 4-Post Rack, 22U
Constructed of 12-gauge cold-rolled steel.
Four-post stability.
Open design provides maximum ventilation.
M6 mounting.
Shipped unassembled.
Assembly hardware and mounting hardware are included.
EIA 310-D compliant.
Also available in 15U, 37U, 42U, 51U, and 58U.

With solid four-post construction in a standard rack size at a very economical price, 4-Post Racks from Black Box are data center staples!

Our 4-Post Rack combines the stability of a cabinet with the airflow of an open rack. It's tough, too - its 12-gauge steel, quality construction supports more than a ton of equipment!

The rack ships unassembled for easy transport to your site. Assembly is simple with the included hardware. You can install it as a standalone rack or bay it. To bay the rack, use our Baying Kit (RM7002-R2).

The rack conforms to the EIA standard for 19" equipment mounting and features universal M6 mounting holes. It comes with 50 M6 cage nuts and screws for mounting.

• Guaranteed for life!


• Weight capacity is 2000 pounds (750 pounds when on casters).


• All four uprights have RMU labels.

Product Type: Rack Frame
Maximum Weight Capacity: 2200 lb
Product Material: Cold-rolled Steel (CRS)
Country Of Origin: Taiwan
Assembly Required: Yes
Rack Height: 22U
Brand Name: Black Box
Manufacturer: Black Box Corporation
Product Model: RM7001A-R3
Product Name: 4-Post Rack, 22U
Manufacturer Part Number: RM7001A-R3
Manufacturer Website Address: http://www.blackbox.com
Package Contents:

• 4-Post Rack, 22U
• 4 x 45.5"H universal cage nut uprights
• 4 x 23"D horizontal depth brackets
• 4 x top/bottom horizontal width brackets
• 16 x 3/8"-16 x 3/4" flathead screws
• 16 x 1/2"-13 x 1" hex head bolts
• 16 x 1/2" x 13 hex nuts
• 16 x 1/2" split-locking washers
• 50 x M6 cage nuts
• 50 x M6 screws
• Manual
