Fast Ethernet Hardened Temperature Switch(2)10/100-Mbps Copper Rj45,(1)100-Mbps Bbx-Lbh100A-Hd-Sc-24

Description :

Black Box Fast Ethernet Hardened Temperature Switch - (2) 10/100-Mbps Copper RJ45, (1) 100-Mbps Multimode Fiber, 1300nm, 2km, SC, 24V DC-Power, DIN Rail
Use Standard Media Converter Switches in clean, temperaturecontrolled areas of +32 to +104° F (0 to +40° C), such as offices and closets.
Hardened Media Converter Switches suit -13 to +140° F (-25 to +60° C) operation in dusty or dirty environments. Their sealed cases are a heat sink, so no internal airflow is needed for cooling, and they resist contaminants such as dust, dirt, and moisture.
For harsher environments of -40 to +167° F (-40 to +75° C), choose Extreme Media Converter Switches. These rugged units are for outdoor use (they only require protection from water) and feature a sealed case, which uses its own metal shell as a heat sink.

• 24-VDC power input.


• Includes DIN rail mount kit.


• Suitable for dusty or dirty environments with a temperature range between -13 and +140 F (-25 to +60 C).


• Fiber interface is MM, SC, 2km range.


• One 100-Mbps fiber port and two 10-/100-Mbps RJ45 switch ports.

Product Type: Transceiver/Media Converter
Environmentally Friendly: Yes
Environmental Certification: RoHS
Taa Compliant: Yes
Country Of Origin: United States
Product Series: LBH100
Brand Name: Black Box
Form Factor: Rail-mountable
Manufacturer: Black Box Corporation
Product Model: LBH100A-HD-SC-24
Product Name: LBH100A-HD-SC-24 Transceiver/Media Converter
Manufacturer Part Number: LBH100A-HD-SC-24
Manufacturer Website Address: http://www.blackbox.com
Package Contents:

• LBH100A-HD-SC-24 Transceiver/Media Converter


• DIN Rail Bracket
