Comnet Video Transmitter/Data Transceiver Fvt4014S1Shr

Description :

ComNet Video Transmitter/Data Transceiver
The ComNet™ FVT/FVR4014SHR series of optical video links provides four 10-bit digital video channels, medium haul video quality, and four bi-directional data channels and a "Dual Optical Port" (DOP) Self-Healing Ring (SHR) topology. Up to (8) video channels and multiple video receivers can be "Daisy Chained" on one optical fiber. The Self-Healing Ring (SHR) topology using the Dual Optical Ports (DOP) provide fail safe operation in the event of loss of one fiber or one optical module. Each optical port uses wavelength division multiplexing (WDM) to both transmit and receive on one optical fiber. The data channels support RS232, RS422 and 2 wire and 4 wire RS485. Plug-and-play design ensures ease of installation and no electrical or optical adjustments are ever required. Bi-color (Red/Green) LED indicators are provided for confirming operating status. These units are interchangeable between stand-alone or card mount configurations.

Product Type: Video Extender Transceiver
Environmentally Friendly: Yes
Environmental Certification: RoHS
Brand Name: ComNet
Form Factor: Rack-mountable
Manufacturer: ACRE
Product Model: FVT4014S1SHR
Product Name: Video Transmitter/Data Transceiver
Manufacturer Part Number: FVT4014S1SHR
Manufacturer Website Address: http://www.acre-co.com
Package Contents:

• 9 Volt DC Plug-in Power Supply
• RJ45 Breakout Wiring Kit (Cable and Terminal Block)
