Club 3D Displayport 1.4 Cable To Hdmi 2.0B Active Adapter Male/Male 2M/6.56 Ft

Description :

Club 3D DisplayPort 1.4 Cable To HDMI 2.0b Active Adapter Male/Male 2m/6.56 ft
CAC-1082 - The Club3D CAC-1082 is a DisplayPort 1.4 to HDMI 2.0b signal converter cable. It features support for HDR Video quality for deep color media content playback. The DisplayPort receiver supports up to 5,4 Gbps per lane over 4 lanes. The HDMI output is fully compliant to HDMI specification version 2.0b.

Supports up to 4K UHD Resolutions

The CAC-1082 supports UHD resolutions up to 4096 x 2160p at 60Hz.

Color Formats

It supports RGB/YCbCr video color formats with a color depth of 16bpc (or 48 bits per pixel) as long as it fits within the DisplayPort and HDMI link bandwidth. The CAC-1082 also supports pixel encoding conversion from RGB or YCbCr 4:4:4 to YCbCr 4:2:0 and YCbCr 4:2:0 pass-trough function. In addition HDR with deep color up to 12Bpc at 4K 60Hz is supported through the conversion of RGB/YCbCr 4:4:4 over DP link to YCbCr 4:2:0 on the HDMI output with a horizontal expansion to CEA timings.

• DisplayPort™ 1.4 Receiver, up to 5.4Gbps link Rate, HBR2/HBR/RBR


• Video Stream Handling: - Up to 600Mhz dual pixel path and 16bpc, RGB/YCbCr 4:4:4/4:2:2/4:2:0 pixel format, Horizontal expansion of Vesa CVT to CEA Timings (as per DP™ 1.4 spec)


• DisplayPort™ to HDMI™ Stereoscopic 3D Transport: Frame Sequential to Stacked Top-Bottom Conversion, Pass-trough of ther 3D Formats


• Audio Stream Handling: LPCM and compressed Audio encoding formats, Max audio sample rate of 192 Khz x 8 Channel or 768 KHz x 2 Channel


• HDCP Support: HDCP 1.3 to HDCP 1.4 Repeater function, HDCP 2.2 to HDCP 1.4 and 2.2 Repeater Fucntion


• HDMI™ transmitter: Compliant to HDMI™ specifications version 2.0b, 600MHz max TMDS character clock, High Daynamic Range (HDR) support both Static- and Dynamic HDR, CEC Support - snooping, tunneling


• Max Video resolution and color depth on HDMI™ output: 4K 60Hz RGB/YCbCr 4:4:4, 8bpc, 4K 60Hz YCbCr 4:2:2, up to 12bpc, 4K 60Hz YCbCr 4:2:0, up to 16bpc, 4K 30Hz RGB/YCbCr 4:4:4, up to 16Bpc

Product Type: A/V Cable
Environmentally Friendly: Yes
Environmental Certification: RoHS
Taa Compliant: No
Brand Name: Club 3D
Manufacturer: Club 3D
Product Name: DisplayPort 1.4 Cable To HDMI 2.0b Active Adapter Male/Male 2m/6.56 ft
Manufacturer Part Number: CAC-1082
Manufacturer Website Address: http://www.club-3d.nl
Weight (Approximate): 0.19 lb
