Cisco C240 M4 2U Rack Server - 2 X Intel Xeon E5-2620 V3 2.40 Ghz - 128 Gb Ram - 12Gb/S Sas, Serial Ata Controller

Description :

Cisco C240 M4 2U Rack Server - 2 x Intel Xeon E5-2620 v3 2.40 GHz - 128 GB RAM - 12Gb/s SAS, Serial ATA Controller

Storage and I/O-Optimized Cisco UCS C-Series Rack Servers

Delivering Outstanding Performance and Expandability

The Cisco UCS® C240 M4 Rack Server is our newest 2-socket, 2-rack-unit (2RU) rack server. It offers outstanding performance and expandability for a wide range of storage and I/O-intensive infrastructure workloads, from big data to collaboration. The enterprise-class Cisco UCS C240 M4 server extends the capabilities of the Cisco Unified Computing System™ (Cisco UCS) portfolio in a 2RU form factor with the addition of the Intel® Xeon® processor E5-2600 v3 product family, which delivers a superb combination of performance, flexibility, and efficiency.

Product Overview

The enterprise-class Cisco UCS C240 M4 server extends the capabilities of the Cisco UCS portfolio in a 2RU form factor. Based on the Intel® Xeon® processor E5-2600 v3 series, it delivers an outstanding combination of performance, flexibility, and efficiency. In addition, the Cisco UCS C240 M4 offers outstanding levels of internal memory and storage expandability with exceptional performance. It delivers:

? Up to 24 DDR4 DIMMs for improved performance and lower power consumption

? Up to 6 PCI Express (PCIe) 3.0 slots (4 full-height, full-length)

? Up to 24 small form factor (SFF) drives or 12 large form factor (LFF) drives, plus two (optional) internal SATA boot drives

? Support for 12-Gbps SAS drives

? A modular LAN-on-motherboard (mLOM) slot for installing a next-generation Cisco virtual interface card (VIC) or third-party network interface card (NIC) without consuming a PCIe slot

? 2 x 1 Gigabit Ethernet embedded LOM ports

? Supports up to two double-wide NVIDIA graphics processing units (GPUs), providing a graphics-rich experience to more virtual users

? Excellent reliability, availability, and serviceability (RAS) features with tool-free CPU insertion, easy-to-use latching lid, hot-swappable and hot-pluggable components, and redundant Cisco® Flexible Flash (FlexFlash) SD cards.

• Experience high performance, built-in security and remote management capabilities with Intel Xeon 2.40 GHz processor


• Up to 10x faster than standard Ethernet connectivity and provides high-performance uplinks


• RAID provides data reliability, fault tolerance and improves overall performance through RAID levels (0, 1, 5, 10)


• 128 GB memory enables you to do multitasking and run intensive applications lag-free


• 1400 W power supply unit (PSU) included

Product Type: Server
Product Series: C240 M4
Rack Height: 2U
Brand Name: Cisco
Form Factor: Rack
Manufacturer: Cisco Systems, Inc
Product Name: SmartPlay Select C240M4-Standard-2
Manufacturer Part Number: UCS-SPL-C240M4-S2
Manufacturer Website Address: http://www.cisco.com
Limited Warranty: 3 Year
