Black Box Kvm Extender - 4K@60Hz, Hdmi 1.4, Usb 2.0, Cat5E/6/6A

Description :

Black Box KVM Extender - 4K@60Hz, HDMI 1.4, USB 2.0, CAT5e/6/6A

Use the KVM Extenders to send high-resolution 4K@60Hz (4:2:0 8-bit) video as well as signals for USB keyboards, mice, and other human interface devices (HID), and power and control signals. The extender includes a local unit that attaches to the CPU and a remote unit that connects the user's KVM console. But you can also plug in a monitor on the local side - which is great for monitoring and administration right at the computer. Requires only one power supply.

• Extend uncompressed 4Kx2K@60Hz and 1080p@60Hz up to 100 meters over CAT6, CAT6A cables and up to 90 meters over CAT5 cable


• Transmit video, analog stereo, power, RS-232 and USB 2.0 signals


• With integrated 48V PoC, only one power supply is needed to power both units


• Locking power supply prevents the power from being accidentally disconnected


• An analog audio pass through from Transmitter to Receiver


• HDMI 1.4 Compliance


• Four USB Type-A inputs for keyboard, mouse, or additional peripherals

Product Type: KVM Extender
Environmentally Friendly: Yes
Environmental Certification: RoHS
Product Condition: New
Brand Name: Black Box
Manufacturer: Black Box Corporation
Product Name: KVM Extender - 4K@60Hz, HDMI 1.4, USB 2.0, CAT5e/6/6A
Manufacturer Part Number: ACU1700A
Manufacturer Website Address: http://www.blackbox.com
Package Contents:

• 1 x Transmitter
• 1 x Receiver
• 1 x 12VDC, 2A Power Supply
• 4 x Power Cords (US, UK, EU, AU)
• 2 x 3-Pin Phoenix connectors
• 2 x Mounting brackets + 4 screws
