Apc Service Bypass Panel- 200/208/240V Power Distribution Unit (Pdu) Black

Apc Service Bypass Panel- 200/208/240V Power Distribution Unit (Pdu) Black


Regular price $1,635.74
Regular price Sale price $1,635.74
Sale Sold out
Shipping calculated at checkout.
          View full details
          Reviews, Que. & Ans.

          Description :

          Service Bypass Panel- 200/208/240V; 50A; MBB; L6-30P/HW input; (1) L6-30R (2) L6-20R output

          APC Service Bypass Panel- 200/208/240V. Product colour: Black. Input connection type: Hard Wire 3-wire (2PH + G), NEMA L6-30P, Output connections: 2x NEMA L6-20R 1x NEMA L6-30R. Cable length: 3.05 m, Certification: CSA,EN 60950,GOST,IEC 60950,IEC 60950,UL 1778. Load capacity: 6000 VA, Maximum input current per phase: 30 A, Maximum total current draw per phase: 30 A. Dimensions (WxDxH): 432 x 650 x 89 mm, Weight: 13.6 kg

          19 inch Rack-Mountable
          Supplies redundant AC power to connected equipment. Two AC lines power the unit and if the primary AC power fails, the unit will automatically switch to the alternate power source.

          Quick Transfer Rate
          Transfer rate is within the industry standard and within the time power supplies will typically drop loads. The transfer of one power source to another is seamless to the connected equipment avoiding disruption of equipment performance.

          Wrap Around System Bypass
          (3) Breaker maintenance bypass panel to isolate the UPS from the critical load
          Meets UL Requirements

          Specifications :

          General Information

          Manufacturer Schneider Electric SA
          Manufacturer Website Address
          Brand Name APC by Schneider Electric
          Product Name 19" Rack Mountable 100A Maintenance Bypass Panel
          Product Type Bypass Panel
          UPC 731304212621

          Physical Characteristics

          Color FamilyBlack
          Product ColorBlack
          Weight (Approximate)48.10 lb


          Package Contents
        • 19" Rack Mountable 100A Maintenance Bypass Panel
        • Installation guide
        • Rack mounting brackets
        • User manual
        • Environmentally FriendlyYes
          Environmental CertificationRoHS


          Limited Warranty2 Year
          Additional Warranty Information2 years (parts only)
