Advantech Slide-In Modular Media Converter 10/100Mbps to Fiber Series IMC-762-SFP

Advantech Slide-In Modular Media Converter 10/100Mbps to Fiber Series IMC-762-SFP

SKU:IMC-762-SFP

Regular price $318.18
Regular price Sale price $318.18
Sale Sold out
Shipping calculated at checkout.
          View full details
          Description
          Specifications
          Reviews, Que. & Ans.

          Description :

          Advantech Slide-In Modular Media Converter 10/100Mbps to Fiber Series
          The IMC-760 series of intelligent media converters connect a host/remote Ethernet network over a fiber optic or CAT5 copper connection. It combines media conversion with an advanced-feature set for network management and troubleshooting, including OAM (operation, administration, and management). Administrators can observe the end-points over the fiber segment between them as a single management entity. Bandwidth scalability and support for MIBs II makes this modular device a cost-effective solution.

          The SNMP software, iView2 , allows for remoteconfiguration and alerts administrators to any potential problems on the long-haul fiber run, providing vital information on link conditions and reporting data on traffic statistics. With iView2 , the central location can manage all host/remote pairs installed in the IMC-71x series with the single IP address of the chassis.


          • SNMP manageable

          • OAM IEEE802.3ag/ah (operation, administration, and management)

          • Supports per-port, bi-directional bandwidth control

          • Supports powerful LinkLoss, FiberAlert and Loopback troubleshooting functions

          • All management traffic remains isolated from the remote LAN

          • The modular, hot-swappable architecture reduces operational costs associated with product installation, upgrades, and maintenance

          Product Type: Transceiver/Media Converter
          Environmentally Friendly: Yes
          Environmental Certification: RoHS
          Product Series: IMC-760
          Brand Name: Advantech
          Form Factor: Hot-swappable
          Manufacturer: Advantech Co., Ltd
          Product Name: Slide-In Modular Media Converter 10/100Mbps to Fiber Series
          Manufacturer Part Number: IMC-762-SFP
          Manufacturer Website Address: http://www.advantech.com
          Weight (Approximate): 3.88 oz

          Specifications :

          General Information

          Manufacturer Advantech Co., Ltd
          Manufacturer Part Number IMC-762-SFP
          Manufacturer Website Address http://www.advantech.com
          Brand Name Advantech
          Product Series IMC-760
          Product Name Slide-In Modular Media Converter 10/100Mbps to Fiber Series
          Product Type Transceiver/Media Converter
          Ethernet TechnologyFast Ethernet
          Network (RJ-45)Yes
          Height4.2"
          Width0.8"
          Depth2.8"
          Weight (Approximate)3.88 oz
          Environmentally FriendlyYes
