Advantech 8GE PoE + 2G SFP + 2 VDSL2 Port Managed Redundant Industrial Switch EKI-7712G-2FVP-AE

Description :

Advantech 8GE PoE + 2G SFP + 2 VDSL2 Port Managed Redundant Industrial Switch
The EKI-7712G and EKI-7708G-2FVP support 8/4 Gigabit PoE ports, 2 Gigabit SFP ports, and 2 VDSL2 ports. They offer abundant port options for connecting many different device types. The embedded Advantech IXM function facilitates fast deployment, which can dramatically save on engineering time and costs. The series also support NMS to help IT managers with networking maintenance and failure prevention. Finally, they are equipped with X Ring Pro redundancy for ultra-high-speed recovery times of <20 ms. The switches also incorporate the latest VDSL2 technology, meaning that this SFP module can be easily adapted to existing applications with existing 2-wire cable (e.g., phone line), thus avoiding the cost of rewiring. Furthermore, they can drastically extend Ethernet service on UTP wire up to 3000 m, and even with a rate of 100 Mbps up to 400 m on a standard CAT 5e2 wire cable.

• Dual 48 VDC (46 to 57 VDC) power input and 1 relay output


• Provide 100/100 Mbps up to 400m over CAT 5e


• EN50121-4 approval for railway trackside deployment


• NEMA TS2 for traffic control


• Management: SNMP v1/v2c/v3, WEB, Telnet, Standard MIB, Private MIB


• Security: 802.1x (Port-Based, MD5/TLS/TTLS/PEAP Encryption), RADIUS


• IXM function enables fast deployment


• Redundancy: X-Ring Pro (ultra high-speed recovery time < 20 ms), RSTP/STP and MSTP (802.1w/1D/1s)

Product Type: Ethernet Switch
Environmentally Friendly: Yes
Environmental Certification: RoHS
Brand Name: Advantech
Form Factor: Wall Mountable
Manufacturer: Advantech Co., Ltd
Product Model: EKI-7712G-2FVP
Product Name: 8GE PoE + 2G SFP + 2 VDSL2 Port Managed Redundant Industrial Switch
Manufacturer Part Number: EKI-7712G-2FVP-AE
Manufacturer Website Address: http://www.advantech.com
Limited Warranty: 5 Year
Weight (Approximate): 7.76 oz
