Black Box DKM FX Matrix KVM Switch ACXC8FHS

Description :

Black Box DKM FX Matrix KVM Switch

The switches are for smaller KVM systems and use the same technology as in our larger DKM switches. Choose from CATx, fiber (1-Gbps), high-speed fiber (3-Gbps) or combinations (6-Gbps) (6-Gbps). They work with DKM extender modules.

• Control via hotkeys, on-screen display, eternal Java Utility or an API interface.


• Mix and match. Fiber ports can be switched to CATx ports.


• Supports DisplayPort, DVI-D, DVI-I, USB 2.0, USB HID, RS-232, RS-422 and analog/digital audio. Contact us to support legacy interfaces.


• Can be easily cascaded to support future expansion.


• Each port is agnostic and can support a transmitter or receiver.


• Supports central management of all attached endpoints, including firmware upgrading, user access control, configuration, etc.


• Enables instant matrix switching support for eight high-speed fiber endpoints. For example, you can have seven computers and one user or seven users and one computer.

Product Type: KVM Switchbox
Environmentally Friendly: Yes
Environmental Certification: RoHS
Product Series: DKM FX Compact
Brand Name: Black Box
Form Factor: Desktop
Manufacturer: Black Box Corporation
Product Model: ACXC8FHS
Product Name: DKM FX Matrix KVM Switch
Product Line: ServSwitch
Manufacturer Part Number: ACXC8FHS
Manufacturer Website Address: http://www.blackbox.com
Package Contents:

• DKM Compact KVM Matrix Switch - Redundant Power, Universal, SFP, 8-Port
• 1 x US power cord
• 1 x RJ-45 adapter
• 4 x Rubber feet
• User Manual
