Taoglas Shockwave TLS.01 4G/3G/2G Terminal Antenna 3M CFD200 Fakra Code D TLS.01.305721

Description :

Taoglas Shockwave TLS.01 4G/3G/2G Terminal Antenna 3M CFD200 Fakra Code D

The Shockwave TLS.01.305721 is a permanent mount, waterproof, external 2G/3G/4G cellular and GPS antenna operating at 698-960/1575.42/1710-2700MHz with an N type male connector. It has been designed to be used on a Ground Plane. It can be used in mobile and fixed applications for 4G LTE wireless such as:

• Public safety
• HD Video Streaming
• Utilities and Smart Cities
• Fleet Management
• Agricultural
• Industrial

This antenna has superior performance over wide-bands compared to traditional whip antennas. Up to 77% efficiency and with a minimum 2.2dBi peak gain over all cellular bands result when mounted on a 30x30 cm ground plane. Stable radiation patterns over low angles provides consistent gain in the horizontal plane, meaning that it is especially suitable for cellular applications.

A unique indent tab on the base of the antenna allows a wrench to be used to solidly lock the antenna on top of its mounting location while tightening up the nut beneath the metal panel. Waterproof O-rings around the bottom base prevent water from leaking under the antenna.

The TLS.01 antenna is IP67 waterproof and IP69K resistant against high pressure water jets in commercial cleaning environments, which makes the antenna ideal for 2G/3G/4G application either in indoor or in harsh outdoor environments.

• Applicable for 2G/3G/4G cellular bands and GPS


• Over 45 % efficiency and 2.2 dBi gain


• Mechanically robust for indoor/outdoor applications


• Height: 79.45mm(3.13") ; Diameter : 42mm(1.65")


• IP67 and IP69K Waterproof


• Low loss CFD-200 cable, 3 meters


• Fakra Code D connector


• RoHS compliant

Product Type: Antenna
Environmentally Friendly: Yes
Environmental Certification: RoHS
Product Color: Black
Diameter: 1.65"
Country Of Origin: Taiwan
Brand Name: Taoglas
Form Factor: Panel
Manufacturer: Taoglas
Product Name: Shockwave TLS.01 4G/3G/2G Terminal Antenna 3M CFD200 Fakra Code D
Package Type: Tray
Product Line: Shockwave
Application/Usage: Outdoor
Manufacturer Part Number: TLS.01.305721
Manufacturer Website Address: http://www.taoglas.com
Packaged Quantity: 100
Weight (Approximate): 9.52 oz
