Advantech 4GE + 2G SFP + 2 VDSL2 Port Managed Redundant Industrial Switch EKI-7708G-2FV-AE

Description :

Advantech 4GE + 2G SFP + 2 VDSL2 Port Managed Redundant Industrial Switch
The EKI-7712G-2FV and EKI-7708G-2FV provide 8/4 Gigabit ports, 2 Gigabit SFP ports, and 2 VDSL2 ports. These switches provide abundant port options, thus providing support for connecting a range of different devices. They also come embedded with Advantech IXM function for fast deployment, thus have a marked impact in saving on engineering time and costs. This series also support NMS to help IT managers with networking maintenance and failure prevention. Finally, they are equipped with X-Ring Pro redundancy for ultra-high-speed recovery times of <20 ms. These switches also incorporate the latest VDSL2 technology and can be easily adapted to existing applications with existing 2-wire cable (e.g., phone line systems), thus avoiding unnecessary costs associated with rewiring. It can substantially extend Ethernet service on UTP wire with distances up to 3000 m, and even with a rate of 100Mbps for up to 400 m on standard CAT-5e2 cable.

• Dual 12 ~ 48 VDC power input and 1 relay output


• Provide 100/100 Mbps up to 400m over CAT 5e


• EN50121-4 approval for railway trackside deployment


• NEMA TS2 for traffic control


• Management: SNMP v1/v2c/v3, WEB, Telnet, Standard MIB, Private MIB


• Security: 802.1x (Port-Based, MD5/TLS/TTLS/PEAP Encryption), RADIUS


• IXM function enables fast deployment


• Redundancy: X-Ring Pro (ultra high-speed recovery time < 20 ms), RSTP/STP and MSTP (802.1w/1D/1s)

Product Type: Ethernet Switch
Environmentally Friendly: Yes
Environmental Certification: RoHS
Brand Name: Advantech
Form Factor: Wall Mountable
Manufacturer: Advantech Co., Ltd
Product Model: EKI-7708G-2FV
Product Name: 4GE + 2G SFP + 2 VDSL2 Port Managed Redundant Industrial Switch
Manufacturer Part Number: EKI-7708G-2FV-AE
Manufacturer Website Address: http://www.advantech.com
Limited Warranty: 5 Year
Weight (Approximate): 2.43 lb
