Mellanox DAC splitter cable, 400GbE, 400Gb/s to 2x200Gb/s, QSFP-DD to 2xQSFP56, 1m, 30AWG MCP7H60-W001R30

Description :

NVIDIA 400GbE to 2x200GbE (QSFP-DD to 2xQSFP56) Direct Attach Copper Splitter Cable

400GbE to 2x200GbE / QSFP-DD to 2xQSFP56 Direct Attach Copper Splitter Cable

NVIDIA MCP7H60-W001R30 DAC splitter cables are a high speed, cost-effective 400GbE QSFP-DD to 2x200GbE QSFP56 Ethernet connectivity solution, designed to meet the growing needs for higher bandwidth in data centers.

MCP7H60-W001R30 cables provide connectivity between systems with a QSFP-DD port on one side and up to two different QSFP56 ports on the other side (8x to two 4x). Each of the ports comprises an EEPROM providing product information, which can be read by the host system.

NVIDIA's unique quality passive copper cable solutions provide power-efficient connectivity for short distance interconnects. They enable higher port bandwidth, density and configurability at a low cost and reduced power requirement in the data centers.

Rigorous cable production testing ensures best out-of-the-box installation experience, performance and durability.

• 400GbE to 2x200GbE data rate


• SFF-8636 compliant I2 C management interface


• Operating case temperature 0-70°C


• BER (Bit Error Rate) better than 1E-15 with Mellanox end-to-end interconnect


• Hot pluggable


• RoHS compliant


• LSZH (Low Smoke Zero Halogen) jacket


• LF (Lead Free) HF (Halogen Free) PCB

Product Type: Network Cable
Product Color: Black
Product Material: Copper
Brand Name: NVIDIA
Manufacturer: Mellanox Technologies Ltd
Product Name: 400GbE to 2x200GbE (QSFP-DD to 2xQSFP56) Direct Attach Copper Splitter Cable
Product Line: LinkX
Manufacturer Part Number: MCP7H60-W001R30
Manufacturer Website Address: http://www.mellanox.com
Limited Warranty: 1 Year
