Middle Atlantic BGR-3827-AV Rack Cabinet
A pre-configured BGR Built for today's AV systems. The accessories and options included with the Pre-Configured BGR for AV are exactly what you need to deliver an optimized AV system.
- All BGRs are now equipped with the revolutionary Forward rackrail giving you the ability to use Forward blank panels,vent panels horizontal cable management and vertical cable management
- Provides more rackspace in a smaller overall height than similar racks
- Accepts patented Lever Lock™ tool free and hardware free internal device and cable management system accessories
- Fully welded construction provides the following weight capacities: UL Listed load capacity: 3,000 lbs., Seismic certified capacity: 1,175 lbs.
- Pre-threaded ganging holes allow for rack joining after loading
- Rackrail depth indicators
- 1/2", 3/4", 1" & 1-1/2" electrical knockouts and 5/8" and 1/2" D UHF/VHF antennae knockouts on rear top & bottom, easily removable for cable pass-through. Top cable management plate (38 space and up) includes 1/2", 3/4", 1" 1-1/2" & 3" electrical knockouts and 5/8" and 1/2" D UHF/VHF antennae knockouts
- 23" OD width, multiple depths
- Two pairs of 11-gauge, 10-32 threaded rackrail with numbered rackspace increments
- Optional stackable 3" extender bay available for front and rear
Product Type: Rack Cabinet
Environmentally Friendly: Yes
Environmental Certification: EU RoHS
Maximum Weight Capacity: 3000 lb
Rack Depth: 24.40"
Product Color: Black Powder Coat
Product Material: Steel
Product Series: BGR
Rack Width: 19"
Rack Height: 38U
Brand Name: Middle Atlantic
Form Factor: Floor Standing
Manufacturer: Legrand Group
Product Model: BGR-3827-AV
Product Name: BGR-3827-AV Rack Cabinet
Manufacturer Part Number: BGR-3827-AV
Manufacturer Website Address: http://www.legrand.us
Package Contents:
- BGR-3827-AV Rack Cabinet
- 4 x Forward 1RU Flanged Blank Panels
- 2 x Forward 2RU Flanged Blank Panels
- 1 x 4pk of Forward Straight Horizontal Lacer Bar
- 1 x 4pk of Forward 2" Offset Horizontal Lacer Bar
- 1 x Forward Vertical Wire Grid Lace
- 1 x Forward Vertical Cable Management Lace
- 2 x Lever Lock Vertical Channel
- 1 x 15pk of Forward Tie Saddles
- 2 x Velcro Straps for Tie Saddles
- 2 x 4pk of Forward Small Device Clamps
- 1 x Lever Lock Plate For Small Device Mounting
- 1 x DC Fan Top
- 1 x Solid Front Door
- 1 x Pair Of Side Panels
- 1 x Set Of Leveling Feet
- 100 x 10-32 Threaded Rackscrews (HP)
Limited Warranty: Lifetime
