Description :
Rack PDU, Basic, Zero U, 20A, 208V, (20)C13 & (4)C19APC Basic Rack 4160VA. Product colour: Black. Input connection type: NEMA L6-20P, Output connections: (20) IEC 320 C13 (4) IEC 320 C19. Cable length: 3.05 m, Certification: cUL,CSA C22.2 No. 60950-1-03,UL 60950-1,UL. Nominal input voltage: 208 V, AC input frequency: 50 - 60 Hz, Nominal output voltage: 208 V. Dimensions (WxDxH): 56 x 44 x 1619 mm, Weight: 4.86 kg
-Redundant Internal Power Supplies.
-Toolless mounting capability.
-Vertical mounting capability.
-Rack-Mountable: Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
-Single input power source: Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections.
-Wide range of input and output connections: Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip.
Specifications :
General Information
Manufacturer | Schneider Electric SA |
---|---|
Manufacturer Website Address | http://www.schneider-electric.com |
Brand Name | APC by Schneider Electric |
Product Line | Basic Rack |
Product Name | Basic Rack 4160VA PDU |
Product Type | PDU |
UPC | 731304207931 |
Product Color | Black |
---|---|
Height | 63.7" |
Width | 2.2" |
Depth | 1.7" |
Weight (Approximate) | 10.71 lb |
Package Contents | |
---|---|
Environmentally Friendly | Yes |
Environmental Certification | RoHS |
Limited Warranty | 2 Year |
---|---|
Additional Warranty Information | 2 years repair or replace |
