Description :
Rack Pdu, Basic, Zero U, 11 KW, 230V, (36) C13 & (6) C19APC AP7557NA. Product colour: Black. Input connection type: IEC 309 20A 3P+N+E, Output connections: 36x IEC 320 C13 6x IEC 320 C19. Cable length: 0.91 m, Certification: UL 60950-1,UL Listed. Nominal input voltage: 400 V, AC input frequency: 50 - 60 Hz, Nominal output voltage: 230 V. Dimensions (WxDxH): 56 x 44 x 1778 mm, Weight: 5.62 kg
Agility
Rack-Mountable
Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
Single input power source
Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections.
Wide range of input and output connections
Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip.
Specifications :
General Information
Manufacturer | Schneider Electric SA |
---|---|
Manufacturer Part Number | AP7557NA |
Manufacturer Website Address | http://www.schneider-electric.com |
Brand Name | APC by Schneider Electric |
Product Line | Basic Rack |
Product Name | Basic Rack 42-Outlets 11kW PDU |
Product Type | PDU |
UPC | 731304263784 |
Height | 70" |
---|---|
Width | 2.2" |
Depth | 1.7" |
Weight (Approximate) | 12.39 lb |
Package Contents | |
---|---|
Environmentally Friendly | Yes |
Environmental Certification | RoHS |
Limited Warranty | 2 Year |
---|---|
Additional Warranty Information | 2 years repair or replace |
