5In1 Dome Antenna 2Xlte Gnss,Wifi 2.4/5Ghz Bolt Mount 5M Blk Ant

Description :

Sierra Wireless AirLink Antenna: 5-in-1 Dome
The 5-in-1 Dome is a custom single antenna solution for the RV55 Dual Wi-Fi, tested and certified for mobile application.

The antenna has a low-profile design that contains five isolated high performance antenna elements in a single housing for optimal coverage; two ultra-wideband elements spanning 617-6000MHz; a high performance GNSS antenna with an integrated 26dB gain LNA; and two dual band 2.4/5GHz omni-directional Wi-Fi elements.

• Receive signals from multiple directions with this omnidirectional antenna


• Provides gain of up to 26 dB


• Widely used in wireless data network


• Can be mounted as screw mount

Product Type: Antenna
Product Color: Black
Diameter: 7.09"
Brand Name: Sierra Wireless
Compatibility: Sierra Wireless AirLink RV55 Rugged LTE-Advanced Pro Router
Form Factor: Screw Mount
Manufacturer: Sierra Wireless
Product Name: AirLink Antenna: 5-in-1 Dome
Product Line: AirLink
Application/Usage: Wireless Router
Manufacturer Part Number: 6001275
Manufacturer Website Address: http://www.sierrawireless.com
