DVI Extender Equalizer, Single-Link Video Repeater, 1920 x 1200 at 60Hz / 1080p (DVI F/F), up to 45.72 m (150-ft.)
Tripp Lite DVI Extender Equalizer, Single-Link Video Repeater, 1920 x 1200 at 60Hz / 1080p (DVI F/F), up to 45.72 m (150-ft.). Maximum resolution: 1920 x 1080 pixels, Maximum transfer distance: 45.72 m, Product colour: Black. Operating voltage: 5 V, Current: 2 A. Width: 61 mm, Depth: 50.8 mm, Height: 24.1 mm. Package width: 182.9 mm, Package depth: 165.1 mm, Package height: 55.9 mm. Master (outer) case width: 589.3 mm, Master (outer) case length: 348 mm, Master (outer) case height: 221 mm
Tripp Lite's B120-000-SL DVI Single-Link Signal Extender increases the distance a DVI-D signal can be transmitted beyond the recommended 16 ft. (5 m.). Supports DVI Single Link computer video resolutions up to 1920 x 1200, and HD resolutions up to 1080p, as well as a maximum distance of 150 ft. from the source. Use P561-Series DVI Single-Link cables in most applications. When extending a 1920 x 1200 (or 1080p) video signal more than 22.86 m (75-ft.), use cable made with 24Awg wiring. (Available from Tripp Lite as a custom order) Simply connect the longer cable between the source and the B120-000-SL, and the shorter cable (4.88 m (16 ft. or less) between the adapter and the monitor. Software or drivers are not required. Built-in Equalization control to adjust the video image. HDCP and DDC compatible.
- Extend a DVI-D Single-Link signal up to 45.72 m (150-ft.) from the source - Supports DVI Single Link computer video resolutions up to 1920 x 1200, and HD resolutions up to 1080p. - Use P561-Series DVI Single-Link cables in most applications. - When extending a 1920 x 1200 (or 1080p) video signal more than 22.86 m (75 ft.), use cable made with 24Awg wiring
- Extend a DVI-D Single-Link signal up to 45.72 m (150-ft.) from the source - Supports computer video resolutions up to 1920 x 1200, and HD resolutions up to 1080p. - Use P561-Series DVI Single-Link cables in most applications - When extending a 1920 x 1200 (or 1080p) video signal more than 22.86 m (75-ft.), use a cable made with 24Awg wiring (Available from Tripp Lite as a custom order) - Built-in Equalization control to adjust the video image - HDCP and DDC compatible
