Transition Networks M/E-Tx-Fx-01(Sc) Network Media Converter Internal 100 Mbit/S 1300 Nm Multi-Mode Black

Description :

100BASE-TX (RJ-45) 328 ft, 100BASE-FX 1300nm multimode (SC) 1.2 mi, North America

Transition Networks M/E-TX-FX-01(SC). Maximum data transfer rate: 100 Mbit/s, Networking standards: IEEE 802.3u, Ethernet interface type: Fast Ethernet. Fiber optic connector: SC, Connectivity technology: Wired. Maximum transfer distance: 2000 m, Wavelength: 1300 nm, Fiber mode structure: Multi-mode. Product colour: Black. Input voltage: 7.5 V, Power consumption (typical): 2.6 W

Fiber Integration
Used in pairs or as a single unit, this mini media converter will ease the integration of fiber optic cabling into copper-rich Fast Ethernet environments

Extend Network Distance
Fiber supports the transmission of Fast Ethernet data over much longer distances than is possible twisted pair

Low-Latency Design
As a layer-1 design, this Mini converter will retransmit Fast Ethernet signals without any store-and –forward packet inspection delays found in other layer-2 devices

Small Size
Ideal for conversion locations where available space is at a premium
- 65% smaller than standard media converter

FEATURES
- Auto-Negotiation (802.3u)
- Allows devices to perform automatic configuration to achieve the best possible mode of operation over a link.
- AutoCross™
- Automatically detects and configures the twisted pair port on the converter to the correct MDI or MDI-X configuration.
- Far End Fault (FEF)
- A troubleshooting feature that is generally used in conjunction with Link Pass Through to notify both end devices of a loss of link.
- Automatic Link Restoration
- Transition Networks's converters will automatically re-establish link in all network conditions.
- Interoperable with other 100Base-TX/FX NICs, hubs, or switches
- Supports SFP modules
- Supports Jumbo Frames up to 9016bytes
