Mfr Part Number: K5
-
Socket Type: LGA 1150/ 1155/ 1156
-
CPU Application: LGA1155 Supports Intel 3rd Generation Core i3/ i5/ i7 Desktop Processors, LGA1156 Supports Previous Generation Core i3/ i5/ i7 Desktop Processors
-
Material: Aluminum 6063-T5 extruded radial fin heatsink
-
Fan:
-
Rated Speed:
-
At Duty Cycle 20%: 1000 RPM
-
At Duty Cycle 50%: 1800 RPM
-
At Duty Cycle 100%: 2500 RPM
-
Bearing: Double-Ball
-
Rated Voltage: 12V
-
Power:
-
At Duty Cycle 20%: 0.72 W
-
At Duty Cycle 50%: 1.80 W
-
At Duty Cycle 100%: 3.60 W
-
Air Flow:
-
At Duty Cycle 20%: 14.98 CFM
-
At Duty Cycle 50%: 33.80 CFM
-
At Duty Cycle 100%: 46.96 CFM
-
Noise Level:
-
At Duty Cycle 20%: 14.7 dBA
-
At Duty Cycle 50%: 22.7 dBA
-
At Duty Cycle 100%: 29.8 dBA
-
Air Pressure:
-
At Duty Cycle 20%: 0.290 mm-H2O
-
At Duty Cycle 50%: 1.544 mm-H2O
-
At Duty Cycle 100%: 2.98 mm-H2O
-
Lead Wire Pin Out:
- Pin1 - Black (-)
- Pin2 - Yellow (+)
- Pin3 - Green (Techometer / Signal Output)
- Pin4 - Blue (PWM)
-
Dimensions:
-
Fan: 92.0 x 25.0 mm
-
Overall: 92.0 x 41.0 mm
-
Weight: 200.0 g
- RoHS Compliant
General Information
| Manufacturer |
Designed Security, Inc |
| Manufacturer Part Number |
K5 |
| Manufacturer Website Address |
http://www.dsigo.com |
| Brand Name |
DSI |
| Product Model |
K5 |
| Product Name |
K5 Blank Key |
| Product Type |
Blank Key |
| UPC |
855700010121 |
