Advantech Modular Media Converter Chassis
The IMC-71x series provides conversion of Ethernet-to-fiber and a variety of networking technologies. It enables network operators to drastically reduce the capital and operational expenses by providing all copper-to-fiber and multi-mode to single-mode conversions and network distance extensions. This modular approach allows network operators to inexpensively change protocols by simply changing the module rather than the entire unit. With AC or DC power options, it is a economical way to overcome a variety of media and mode conversion challenges.
The IMC-713/716/719 series has the highest port density in the industry -- along with a robust design, hot-swappable architecture, SNMP management via iView , and redundant power supplies for fault tolerance, which a diverse range of applications, using a variety of protocols, require. The temperature controlled fans in the IMC-713/716 chassis activate only when the chassis reaches a certain temperature, thereby extending the life of the fans. The fans on the IMC-719 series can be remotely controlled via SNMP.
- Designed for a variety of media and mode conversion modules
- Supports a wide range of protocols and future-proof upgrade paths
- High flexibility for module combinations for different environments
- Supports AC or DC power
- Standard and extended temperature models available
- Provides 3/6/20-slot chassis that supports low to high density deployment
- Supports SNMP management that uses optional SNMP management module for 3/6/20-slot chassis
- Supports fan test feature
Product Type: Media Converter Chassis
Environmentally Friendly: Yes
Environmental Certification: RoHS
Product Series: IMC-71x
Brand Name: Advantech
Form Factor: Wall Mount
Manufacturer: Advantech Co., Ltd
Product Name: Modular Media Converter Chassis
Product Line: iMediaChassis
Manufacturer Part Number: IMC-711-AC
Manufacturer Website Address: http://www.advantech.com
Weight (Approximate): 1.61 lb
