AtlasIED TSD-ML22VCA Preamplifier - Black

AtlasIED TSD-ML22VCA Preamplifier - Black

SKU:TSD-ML22VCA

Regular price $220.20
Regular price Sale price $220.20
Sale Sold out
Shipping calculated at checkout.
          View full details
          Description
          Specifications
          Reviews, Que. & Ans.

          Description :

          Atlas Sound TSD-ML22VCA Preamplifier - Black
          The TSD-ML22VCA is a 2 input, 2 output true VCA with enhanced features including a high quality microphone pre amplifier. VCA's inserted prior to amplification provide a far more efficient solution than transformer-based attenuators for volume adjustment in high power music applications. The dual channel design can provide level control for two separate discrete zones or stereo sources and is perfect for use in sports bars, restaurants, hotels or other installations.

          The TSD-ML22VCA also provides two high quality, low noise mic pre-amps, which allow simplification of designs that require remote microphone level adjustment. Switchable phantom power is provided for powering condenser microphones and a 12dB/octave @ 125Hz high pass filter is available on each mic input to minimize bass rumble and low frequency feedback in the system ensuring focus and clarity for the voice spectrum.


          • Brings the amazing sonic performance and the fidelity of high-quality sound

          • Soothe yourself with low subs and soaring vocals at 20 kHz maximum frequency

          Product Type: Preamplifier
          Environmentally Friendly: Yes
          Environmental Certification: TV
          Product Color: Black
          Brand Name: Atlas Sound
          Manufacturer: Atlas Sound LP.
          Product Model: TSD-ML22VCA
          Product Name: TSD-ML22VCA 2 x 2 Mic/Line Preamp and VCA
          Manufacturer Part Number: TSD-ML22VCA
          Manufacturer Website Address: http://www.atlassound.com
          Package Contents:

          • TSD-ML22VCA 2 x 2 Mic/Line Preamp and VCA
          • 2 x Mounting Brackets
          • 2 x Cable Retainer
          • Security Covers

          Weight (Approximate): 6 oz

          Specifications :

          General Information

          Manufacturer AtlasIED
          Manufacturer Part Number TSD-ML22VCA
          Manufacturer Website Address http://www.atlassound.com
          Brand Name AtlasIED
          Product Model TSD-ML22VCA
          Product Name TSD-ML22VCA 2 x 2 Mic/Line Preamp and VCA
          Product Type Preamplifier
          UPC 0612079187836
          Product ColorBlack
          Height1.5"
          Width4"
          Depth2.5"
          Weight (Approximate)6 oz

          Miscellaneous

          Package Contents
          • TSD-ML22VCA 2 x 2 Mic/Line Preamp and VCA
          • 2 x Mounting Brackets
          • 2 x Cable Retainer
          • Security Covers
          Environmentally FriendlyYes
          Environmental CertificationRoHS
