ATLASIED

1Input 20W 25V/70V/100V/4 Power,Amplifier

1Input 20W 25V/70V/100V/4 Power,Amplifier

SKU:TSD-PA20VG

Regular price $223.60
Regular price Sale price $223.60
Sale Sold out
Shipping calculated at checkout.
          View full details
          Description
          Reviews, Que. & Ans.

          Description :

          AtlasIED TSD-PA20VG Amplifier - 20 W RMS - 1 Channel - Black

          The TSD-PA20VG is a cost effective mono amplifier for 4? and distributed constant voltage speaker systems. Applications include hallways and classrooms. The TSD-PA20VG is also a cost effective alternative for small projector systems as it can be used with as many as (16) 25/70/100V ceiling speakers (tapped at 1W each), plus the extremely small footprint allows for easy mounting.

          For sound masking applications the TSD-PA20VG has the capacity to drive up to 34 masking speakers tapped at .5W each on a 70.7V line. Output is gain controlled from a potentiometer on the front panel with removable knob.

          Unit requires Power Supply that is sold separately for proper function, multiple TSDs can be powered with one power supply based on current requirements. You must use the TSD24V2500MA power supply. For multiple TSD applications use the TSD Power Calculator to determine the proper power supply needed.


          • Power Supply Sold Separately

          • Compact Chassis Design

          • Energy Efficient

          • Cable Management System

          • Removable Phoenix Style I/O Connectors

          • Input Signal and Peak Indicator LEDs

          • Removable Level Control with Set-It-And-Forget-It Security Cover

          • One (1) Balanced Input

          • 4?/25V/70.7V/100V Output

          Product Type: Amplifier
          Environmentally Friendly: Yes
          Environmental Certification: RoHS
          Product Color: Black
          Product Series: TSD
          Brand Name: AtlasIED
          Manufacturer: Atlas Sound LP.
          Product Model: TSD-PA20VG
          Product Name: TSD-PA20VG Mono Power Amplifier
          Manufacturer Part Number: TSD-PA20VG
          Manufacturer Website Address: http://www.atlassound.com
          Package Contents:

          • TSD-PA20VG Mono Power Amplifier
          • Velcro
          • 2 x Brackets
          • 2 x Cable Retainer

          Limited Warranty: 3 Year
          Weight (Approximate): 5.82 oz
