Gigabyte S451-3R0 Barebone System - 4U Rack-mountable - Socket P LGA-3647 - 2 x Processor Support

Gigabyte S451-3R0 Barebone System - 4U Rack-mountable - Socket P LGA-3647 - 2 x Processor Support

• 2nd Gen. Intel® Xeon® Scalable and Intel® Xeon® Scalable Processors
• 6-Channel RDIMM/LRDIMM DDR4 per processor, 16 x DIMMs
• Supports Intel® Optane™ DC Persistent Memory
• 2 x 10Gb/s SFP+ and 2 x 1Gb/s LAN ports
• 1 x dedicated management port
• 36 x 3.5" SATA/SAS hot-swap HDD/ SSD bays
• 2 x 2.5" SATA hot-swap SSD bays for booting device
• SAS expander with 12Gb/s transfer speed
• 4 x PCIe Gen3 expansion slots
• Aspeed® AST2500 remote management controller
• Dual 1200W 80 PLUS Platinum redundant power supply
• Optimized performance with Mellanox Infiniband EDR and Ethernet 100G products

2nd Generation Intel® Xeon® Scalable Family Ready

GIGABYTE's servers are fully ready to support the second generation of Intel® Xeon® Scalable Family processors, codenamed "Cascade Lake", which bring the following major enhancements:

•
  Intel® Optane™ DC Persistent Memory: Built-in support for this revolutionary new product based on Intel's 3D Xpoint technology
•
  Overall Performance: Higher CPU frequencies, improved turbo profiles vs. prior-gen Intel Xeon Scalable processors
•
  Increased DDR4 Memory Speed & Capacity: Up to 2933MHz (1 DIMM per channel on some SKUs), 16Gb based DIMM supported
•
  Intel Deep Learning Boost: Significantly accelerates inference performance for deep learning workloads optimized to use VNNI (Vector Neural Network Instructions)
•
  Security: Hardware mitigations for Meltdown / Spectre security vulnerabilities

Intel® Xeon® Scalable Family Processors

GIGABYTE's Intel® Xeon® Scalable Processor family servers are available in dual socket configurations, and are compatible with the full family* of different SKUs (Bronze, Silver, Gold and Platinum) that are workload optimized to support different applications, from enterprise IT database, cloud and storage to the most high-demand HPC workloads.

Advanced features built into the silicon include:

•
  Intel® QAT: Speed up data compression and cryptography with integrated Intel QuickAssist Technology (QAT).
•
  Intel® AVX-512: Intel Advanced Vector Extension 512 instruction set architecture enables workload-optimized performance and throughput increases for advanced analytics, high performance computing (HPC) applications, and data compression.
•
  Intel® VROC: Intel Xeon Scalable Processors come with built-in support for Intel VROC (Virtual RAID on CPU). And GIGABYTE Intel Xeon Scalable NVMe SKU servers all ship with an Intel VROC module as standard.
•
  Intel® Omni-Path: Selected GIGABYTE servers support CPU SKUs with integrated Intel Omni-Path Fabric connection

Intel® Optane™ DC Persistent Memory Ready

GIGABYTE's second generation Intel® Xeon® Scalable family servers come ready to support Intel Optane DC Persistent Memory, a revolutionary new product that re-defines traditional memory & storage architectures by enabling a large persistent memory tier between DRAM and SSDs, that's higher capacity than DRAM and faster than SSDs, enabling the user to bring more data closer to the CPU for faster time for insight.

• Perform computational tasks effectively accrediting the Xeon Gold processor


• DDR4 SDRAM compatible slot - Allows the memory to operate at an effective bus speed while using minimal power, resulting in an optimal computer performance and improved memory heat dissipation


• Optimize business network's performance with 10 Gigabit Ethernet connectivity


• With 4 USB ports, connect/disconnect devices while not having to shut down the system


• With Serial ATA/600 interface get superb reliability and high-speed data transfer

Product Type: Barebone System
Environmentally Friendly: Yes
Environmental Certification: RoHS
Rack Height: 4U
Brand Name: Gigabyte
Form Factor: Rack-mountable
Manufacturer: GIGABYTE Technology, Inc
Product Model: S451-3R0
Product Name: S451-3R0 (rev. 100) 4U 38-Bay Dual Processors Storage Server (Intel)
Manufacturer Part Number: S451-3R0
Manufacturer Website Address: http://www.gigabyte.us
Packaged Quantity: 1
Package Contents:

• S451-3R0 (rev. 100) 4U 38-Bay Dual Processors Storage Server (Intel)
• 2 x CPU Heatsinks
• 1 x Rail Kit
• 2 x Non-Fabric CPU Carrier
