QNAP

Qnap Tvs-872Xt-I5-16G-Us Intel Core I5-8400T 1.7Ghz/ 16Gb Ram/ 6Gbe/ 8Sata3/ Usb3.0/ 8 Bay Desktop Nas For Smbs

Qnap Tvs-872Xt-I5-16G-Us Intel Core I5-8400T 1.7Ghz/ 16Gb Ram/ 6Gbe/ 8Sata3/ Usb3.0/ 8 Bay Desktop Nas For Smbs

SKU:TVS-872XT-I5-16G-US

Regular price $2,013.20
Regular price Sale price $2,013.20
Sale Sold out
Shipping calculated at checkout.
          View full details
          Description
          Specifications
          Reviews, Que. & Ans.

          Description :

          • Mfr Part Number: TVS-872XT-I5-16G-US
          • Hardware:
            • CPU: Intel Core i5-8400T Processor (1.37GHz, Quad-Core)
            • Memory:16GB DDR4 RAM (4x 8GB)
            • Flash Memory: 5GB (Dual boot OS protection)
            • M.2 SSD Slot: 2 x M.2 2280 PCIe Gen3 x2 slots
            • Drive Interface: 8 x 3.5-inch SATA 6Gb/s, 3Gb/s
            • Thunderbolt Port: 2x Thunderbolt 3 high-speed Port
            • USB:USB 3.0 port x 1
            • LAN Port: 1 x 10GBASE-T (10G/5G/2.5G/1G/100M)
            • HDMI Output: 1
            • Audio Input:1 x 3.5mm microphone input jacks
            • Audio Output:1 x built-in speaker, 1 x 3.5mm line out jack
            • LED Indicators: HDD 1-8, Status, LAN, USB port, M.2 port
            • Buttons: Power, Reset, USB Copy
            • System Warning:Voice prompts or Buzzer
            • Sound Level: 24.2 db(A)
            • PCIe Slot:PCIe Gen 3 x16 (CPU), PCIe Gen 3 x4 (PCH)
            • Operating System: QTS 4.3 (embedded Linux)
          • Network & Virtual Switch:
            • TCP/IP (IPv4 & IPv6: Dual Stack)
            • Jumbo frame
            • Port trunking:failover, Load balancing
            • DHCP server and client
            • RADVD
            • USB Wi-Fi adapter
            • Virtual switch
              • Network Address Translation (NAT)
              • Spanning Tree Protocol (STP)
              • Thunderbolt to Ethernet converter (T2E)
              • Software-Defined Switch mode
            • Static Route
            • NCSI (Network Connectivity Status Indicator)
            • DDNS settings (Customize & Multiple Service)

          • Security:
            • Network access protection with auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
            • Host access control for shared folders (CIFS/SMB)
            • AES 256-bit folder-based and volume-based encryptions which are validated by FIPS 140-2 CAVP (Cryptographic Algorithm Validation Program)
            • 256-bit external drive encryption (AES)
            • Importable SSL certificates. Supports certificates from Let's Encrypt.
            • Instant alerts via email, SMS, beep, push service, and LCD panel
            • 2-step verification
          • Storage Management:
            • Supported RAID types: 8-bay: RAID 0, 1, 5, 6, 10, 50, 60, JBOD, Single
            • RAID Hot Spare and Global Hot Spare
            • RAID Rebuild Speed Customization
            • Online RAID capacity expansion
            • Online RAID level migration
            • SSD RAID Over-provisioning
            • SSD RAID Performance evaluation (with SSD Profiling Tool)
            • Bitmap support
            • Disk auto S.M.A.R.T. data migration
            • Disk bad block scan and S.M.A.R.T test.
            • Disk bad block recovery
            • Disk secure data erase
            • IronWolf Health Management
            • Storage pools
            • Qtier Data Tiering Technology
              • Automatic or scheduled data tiering
              • IO-aware auto tiering
              • Shared folder tiering on demand
            • Flexible volumes and LUNs with thin provisioning and space reclaiming
            • Online volume expansion Volume type convert
            • Volume shrink
            • Storage space utilization
            • Snapshots
              • Volume and LUN snapshots
              • Snapshot Dashboard
              • Snapshot Manager
              • Snapshot local restore and revert Snapshot Clone
              • Snapshot Replica and Snapshot Vault
              • Snapshot remote restore and revert
              • Unified Snapshot Directory
              • Support for Windows Previous Versions (CIFS/SMB)
              • Snapshot Agent for Microsoft Windows and VMware vSphere
            • Storage expansion using QNAP expansion units
            • JBOD enclosure roaming
            • SSD read-only and read-write cache
            • SSD write-only cache
          • File System:
            • Internal HDD: EXT4
            • External HDD: EXT3, EXT4, NTFS, FAT32, HFS+, exFAT
          • Form Factor: Tower
          • Fan:System - 2x 12cm 12VDC,CPU - 2x 6cm fanblower fan
          • Power Supply: 250W, 100-240V
          • Dimensions:7.41 x12.96 x11.01 inch
          • Weight: 15.56 lbs
          • All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers


          Specifications :

          General Information

          Manufacturer QNAP Systems
          Manufacturer Part Number TVS-872XT-I5-16G-US
          Manufacturer Website Address http://www.qnap.com
          Brand Name QNAP
          Product Model TVS-872XT-I5-16G
          Product Name TVS-872XT-I5-16G SAN/NAS/DAS Storage System
          Product Type SAN/NAS/DAS Storage System
          UPC 885022016471

          Processor

          Processor ManufacturerIntel
          Processor TypeCore i5
          Processor Modeli5-8400T
          Processor CoreHexa-core (6 Core)
          Processor Speed1.70 GHz
          Ethernet Technology10 Gigabit Ethernet

          Interfaces/Ports

          HDMIYes
          Total Number of USB Ports5
          Network (RJ-45)Yes
          Operating SystemQTS 4.3.5

          Power Description

          Maximum Power Supply Wattage250 W
          Height7.4"
          Width13"
          Depth11"

          Miscellaneous

          Package Contents
          • TVS-872XT-I5-16G SAN/NAS/DAS Storage System
          • 2 x Gigabit Ethernet Cables
          • 1 x 10Gbase-T Ethernet Cable
          • Flat Head Screw (for 2.5" HDD )
          • Flat Head Screw (for 3.5" HDD)
          • 2 x M.2 SSD Heatsink
          • 1 x Power Cord
          • Quick Installation Guide (QIG)

          Warranty

          Limited Warranty2 Year
