M602 4G Lte-A Outdoor Router,United States Standard Version

Description :

ZYXEL LTE7461-M602 Wi-Fi 4 IEEE 802.11b/g/n 1 SIM Ethernet, Cellular Modem/Wireless Router

The Zyxel LTE7461-M602 is good for any venue like suburban areas, rural area, public locations, homes, and offices. Enjoy 4G LTE-Advanced technology effortlessly with the LTE7461-M602.

The Fixed Wireless Access (FWA) is an alternative means to provide Internet connectivity that utilizes wireless network technology rather than fixed lines. With a fixed wireless access offering, network operators can supply a vast amount of new customers with broadband Internet connectivity.

Zyxel LTE7461-M602 4G LTE-A Outdoor Router is 3GPP Cat. 6 router, with CA (Carrier Aggregation) to increase data rates and better network quality delivered by an LTE-A based solution. By delivering broadband over mobile networks, operators can rapidly increase revenue from the untapped markets.

The Zyxel LTE7461-M602 4G LTE-A Outdoor Router supports a routing mode with both bridge and router functions, high-gain antenna for better signal performance and robust IP68 outdoor hardware designed for harsh environments - all the necessary features that benefit the critical "second WAN" design. No matter you have a router or not, the LTE7461-M602 can be easily deployed and integrated into your existing environment. You can set 4G LTE-A as your main connection or use LTE7461-M602 as a backup in case the performance of the main fixed internet connection drops.

Download speeds of up to 300 Mbps, UE Cat. 6

Built-In 2x2 MIMO, high-gain antenna of up to 8 dBi per element

Standard IEEE 802.3af/at Power over Ethernet (PoE)

IP68 hardened enclosure with industrial-grade components

Embedded bridge/router modes

Remote management and throughput testing

Zyxel mobile app (iOS and Android)

Benefits

Lightning-fast Internet connectivity

The Zyxel LTE7461-M602 4G LTE-A Outdoor Router employs 3GPP UE Category 6 - the best-practice LTE technology with downlink data rates of up to 300 Mbps through 4 Spatial Streams on two component carriers.

Easy installation with Zyxel mobile app

Easy Installation is realized with a flexible wall or pole mounting kit, integrated 802.3af/at PoE injector support, and dedicated WiFi interface. LTE7461-M602 connects to Zyxel's mobile app with intuitive RF signal strength graphics for base station alignment.

Built-In 2x2 MIMO high-gain antenna

The Zyxel LTE7461-M602 LTE-A Outdoor Router provides 2x2 MIMO high-gain antennas of up to 8 dBi per element that work effectively in outdoor environments. The outdoor design enables it to work under near non-line-of-sight conditions to increase coverage and bandwidth as well as to eliminate edge corners having difficulty accessing good signals.

Non-stop connectivity with LTE 2nd WAN for failover

The wireless LTE allows you to take advantage of the 2nd WAN without a cabling plan. As long as the gateway supports "Multi-WAN failover", you can just connect Zyxel LTE7461-M602 to the existing gateway and set LTE as the failover WAN and relieves the risk of network outage due to the dependence on a single WAN connection.

Remote management, TR-069, HTTP/Web GUI and FTP

Through the LTE radio interface, the Zyxel LTE7461-M602 supports TR-069, remote GUI and remote FTP to be fully configurable and software upgradeable through events triggered by the operators. Thanks to TR-143 remote throughput testing, the troubleshooting can be performed remotely with better efficiency. Additional support TR-069 with TR-181 issue-2 data model also enhances service providers' visibility on subscriber LAN networks for improved customer assistance.

• Savor simultaneous downloading and seamless streaming


• Gigabit Ethernet port for ultra-fast wired network speeds


• Provides electric power over RJ45 ports along with data to devices on your network, such as IP cameras or network equipment


• Uses ISM Band to connect your computers, wireless printers, game consoles, and other Wi-Fi devices for a smooth network experience

Product Type: Modem/Wireless Router
Country Of Origin: Taiwan
Brand Name: ZYXEL
Form Factor: Pole-mountable
Manufacturer: ZYXEL Communications Corp.
Product Model: LTE7461-M602
Product Name: 4G LTE-A Outdoor Router
Manufacturer Part Number: LTE7461-M602
Manufacturer Website Address: http://www.us.zyxel.com
Package Contents:

• 4G LTE-A Outdoor Router
• Ethernet Cable
• Power Cord
• Cable Gland
• Quick Start Guide
• Wall/Pole Mounting Kit
