Intel

Intel R2308Wftzsr Server Barebone Intel® C624 Lga 3647 (Socket P) Rack (2U) Black, Silver

Intel R2308Wftzsr Server Barebone Intel® C624 Lga 3647 (Socket P) Rack (2U) Black, Silver

SKU:R2308WFTZSR

Regular price $2,099.94
Regular price Sale price $2,099.94
Sale Sold out
Shipping calculated at checkout.
          View full details
          Description
          Specifications
          Reviews, Que. & Ans.

          Description :

          Intel® Server System R2308WFTZSR, Single

          Intel R2308WFTZSR. Motherboard chipset: Intel® C624, Processor socket: LGA 3647 (Socket P), Compatible processor series: Intel® Xeon®. Supported memory types: DDR4-SDRAM, Maximum internal memory: 7500 GB. Storage drive sizes supported: 2.5,3.5", Supported storage drive types: HDD & SSD, Supported storage drive interfaces: M.2, Serial ATA III. Ethernet interface type: 10 Gigabit Ethernet, Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000,10000 Mbit/s. Export Control Classification Number (ECCN): 5A992C, Commodity Classification Automated Tracking System (CCATS): G157815L2, Compatible operating systems: Windows Server 2016*|Ubuntu*

          Intel® Virtualization Technology for Directed I/O (VT-d)
          Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

          TPM Version
          TPM (Trusted Platform Module) is a component that provides hardware level security upon system boot-up via stored security keys, passwords, encryption and hash functions.

          Integrated BMC with IPMI
          IPMI (Intelligent Platform Management Interface) is a standardized interface used for out-of-band management of computer systems. The integrated BMC (Baseboard Management Controller) is a specialized microcontroller that enables IPMI.

          PCIe x4 Gen 3
          PCIe (Peripheral Component Interconnect Express) is a high speed serial computer expansion bus standard for attaching hardware devices to a computer. This field indicates the number of PCIe sockets for the given lane configuration (x8, x16) and PCIe generation (1.x, 2.x).

          Integrated Graphics
          Integrated graphics allow for incredible visual quality, faster graphic performance and flexible display options without the need for a separate graphics card.

          Intel® Optane™ Memory Supported
          Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.

          RAID Configuration
          RAID (Redundant Array of Independent Disks) is a storage technology that combines multiple disk drive components into a single logical unit, and distributes data across the array defined by RAID levels, indicative of the level of redundancy and performance required.

          Intel® Remote Management Module Support
          The Intel® Remote Management Module (Intel® RMM) allows you to securely gain access and control servers and other devices from any machine on the network. Remote access includes remote management capability, including power control, KVM, and media redirection, with a dedicated management network interface card (NIC).

          Connector for Intel® Integrated RAID Module
          Internal IO expansion module indicates a mezzanine connector on Intel® Server Boards that supports a variety of Intel(r) I/O Expansion Modules using a x8 PCI Express* interface. These modules are either RoC (RAID-on-Chip) or SAS (Serial Attached SCSI) modules that are not used for external connectivity through the rear I/O panel.

          PCIe OCuLink Connectors (NVMe support)
          Onboard PCIe OCuLink connectors provide direct-attach NVMe SSD support.

          Intel® Rapid Storage Technology enterprise
          Intel ® Rapid Storage Technology enterprise (Intel ® RSTe) provides performance and reliability for supported systems equipped with Serial ATA (SATA) devices, Serial Attached SCSI (SAS) devices, and/or solid state drives (SSDs) to enable an optimal enterprise storage solution.

          # of UPI Links
          Intel® Ultra Path Interconnect (UPI) links are a high speed, point-to-point interconnect bus between the processors, delivering increased bandwidth and performance over Intel® QPI.

          Intel® Node Manager
          Intel® Intelligent Power Node Manager is a platform resident technology that enforces power and thermal policies for the platform. It enables data center power and thermal management by exposing an external interface to management software through which platform policies can be specified. It also enables specific data center power management usage models such as power limiting.

          Intel® Optane™ Persistent Memory Supported
          Intel® Optane™ persistent memory is a revolutionary tier of non-volatile memory that sits between memory and storage to provide large, affordable memory capacity that is comparable to DRAM performance. Delivering large system-level memory capacity when combined with traditional DRAM, Intel Optane persistent memory is helping transform critical memory constrained workloads – from cloud, databases, in-memory analytics, virtualization, and content delivery networks.

          Specifications :

          General Information

          Manufacturer Intel Corporation
          Manufacturer Part Number R2308WFTZSR
          Manufacturer Website Address http://www.intel.com
          Brand Name Intel
          Product Line Server System
          Product Model R2308WFTZSR
          Product Name Server System R2308WFTZSR
          Product Type Barebone System
          UPC 735858406871

          Chipset

          Chipset ManufacturerIntel
          Ethernet TechnologyGigabit Ethernet
          Total Number of USB Ports5

          Power Description

          Maximum Power Supply Wattage1300 W
          Height3.4"
          Width16.9"
          Depth28"

          Miscellaneous

          Package Contents
          • Server System R2308WFTZSR
          • 1 x 2U Chassis with Quick Reference Label affixed to top cover
          • 1 x Intel® Server Board S2600WFTR (dual 10 GbE LAN) S2600WFTR
          • 2 x PCIe Riser card brackets. Includes:
          • 2 x 3-slot PCIe riser cards A2UL8RISER2
          • 1 x 2-slot low profile PCIe riser card A2UX8X4RISER
          • 8 x 3.5" hot-swap drive bays with drive carriers and blanks. Includes:
          • 1 x 12Gb SAS backplane A2U8X35S3HSDK1
          • 8 x 3.5" hot-swap drive tool less carriers FXX35HSCAR2
          • 1 x Standard control panel assembly (board only FXXFPANEL2)
          • 1 x Front I/O panel assembly
          • 1 x 400 mm Backplane power cable
          • 1 x SATA optical drive power
          • 1 x SATA optical drive bay mounting kit
          • 1 x Standard 2U air duct
          • 6 x Hot swap system fans FR2UFAN60HSW
          • 1 x 1300W AC power supply module AXX1300TCRPS
          • 1 x Power supply bay blank insert
          • 2 x CPU heat sinks FXXCA78X108HS
          • 2 x CPU heat sink "NO CPU" Mylar* spacer insert

          Warranty

          Limited Warranty3 Year
