36" X 24" X 16" Nema 3 Enclosure Al362416N3

36" X 24" X 16" Nema 3 Enclosure Al362416N3

SKU:AL362416N3

Shipping calculated at checkout.
View full details
Description
Specifications
Reviews, Que. & Ans.

Description :

36″ X 24″ X 16″ NEMA 3 ENCLOSURE AL362416N3



  • Constructed For Indoor & Outdoor Application
  • Durable 1/8” 5052 Aluminum Construction
  • Weathertight 1/4″ Rubber Door Seals
  • Screened Vents On Sides & Door
  • Adjustable / Removable Equipment Mounting Plate
  • Security Lock with Key
  • A pair of Wall / Pole Enclosure Mount Plates are included
  • Includes Heavy Duty Hardware Adapted for Heavier Installed Equipment

OVERVIEW

36″ x 24″ x 16″ NEMA 3 weatherproof enclosure is manufactured from 5052 Aluminum. This construction resists rusting and corrosion making it ideal for use for marine applications as well as other rugged environments. Each enclosure includes a sunshade, airflow vents with screens, insulation, a heavy-duty piano hinge, dual door latches, triangular cam lock, and universal mounting brackets. These brackets allow for installers to mount the enclosure directly to a wall (flush mount), or mount to a pole using banding brackets (optional accessory). A removable back-plate allows for items to be installed vertically and assembled outside of the enclosure. Temperature control available with an optional thermostatic fan, heater, or both depending on your needs.

Applications: The AL362416N3 is commonly found in data centers, guarding gates, housing controls, along river and ocean fronts, on docks, in boat storage facilities or marinas, commercial areas, and more.

SPECIFICATIONS

Material   1/8" 5052 Aluminum
NEMA Rating   3
Mounting Brackets   Universal Wall / Pole Brackets - Bands not included (x2)
Door Seals   1/4" Weather Tight Neoprene
Equipment Mounting Plate   21" x 34"
Security Lock   Yes (2x keys included)
Dimensions: External   25" W x 37" H x 17.125" D
Dimensions: Internal Max   23.625" W x 35.625" H x 16.5" D
Dimensions: Internal Min   23.625" W x 35.625" H x 12" D
Weight   70 lbs

RESOURCES

PDF Spec Sheet – Download
