Designmax Dm8C White

Description :

Bose Professional DesignMax DM8C 2-way Indoor In-ceiling Speaker - 150 W RMS - White
With coaxial two-way drivers, the 150-watt DesignMax DM8C loudspeaker delivers powerful SPL suitable for foreground music - along with premium aesthetics that complement any commercial sound installation. The DM8C features a two-way, 8-inch woofer and a center-firing coaxial 1-inch compression driver, delivering a 52 Hz - 20 kHz frequency range. The in-ceiling DM8C is installed easily via QuickHold mounting arms.

Key Features

Combine DesignMax models to complete any design, big or small - 12 loudspeakers to mix and match, from 2-inch, low-profile models to 8-inch, high-SPL compression-driver loudspeakers and outdoor-rated options.

Deliver rich lows and clear, intelligible highs with coaxial two-way drivers - no DSP or EQ required. For even better sound, use select Bose DSPs and amplifiers to enable Bose loudspeaker EQ and SmartBass processing, which expands performance and response at any listening level.

Blend with any room design with elegant form factors, minimum-bezel grilles available in black or white, and removable logos.

Reduce installation time with the patented QuickHold mounting system, which also reduces strain, hassle, and the chance of product damage.

Install easily with industry-standard accessories - all models include Euroblock connectors; in-ceiling models include plenumrated backcans, tile bridges, and front-access audio wiring that makes installation and troubleshooting easier.

Deliver high SPL for demanding applications, including high-ceiling venues such as ballrooms, concourse, and convention centers.

• The 2-way speakers give smooth and precise production of sound to deliver an ultimate audio experience


• Uproar the bass as loud as you want with 150 W RMS power without any blaring


• Hear low subs and soaring vocals with a frequency range of sound from 60 Hz-20 kHz


• 8 Ohm impedance extracts maximum power so you will get more output from your speakers

Product Type: Speaker
Cutout Diameter: 13.74"
Speaker Installation: Indoor
Product Color: White
Diameter: 16.1"
Brand Name: Bose Professional
Form Factor: In-ceiling
Manufacturer: Bose Corporation
Product Model: DM8C
Product Name: DesignMax DM8C In-ceiling Loudspeaker
Product Line: DesignMax
Application/Usage: Convention Center
Manufacturer Part Number: 802080-0210
Manufacturer Website Address: http://www.bose.com
Packaged Quantity: 1
Package Contents:

• DesignMax DM8C In-ceiling Loudspeaker
• Adjustable Tile-Bridge
• Template
