4Port 10/100M +1 M.M Fiber,Switch -10 60C Din 12-48Vdc Input

Description :

Advantech 4-Port Ethernet Switch w/ 1-port 100FX Multi-Mode
EKI-2525M/2525S are industrial-grade Ethernet switches that enable you to expand your industrial network fast and cost-effectively. The EKI-2525M/2525S have four 10/100 Mbps Ethernet ports, and additionally the EKI-2525M provides one multi-mode fiber-optic ports, while the EKI-2525S provide one single-mode fiber-optic ports. Using fiber-optics, you can prevent noise from interfering with your system and supports high-speed (100 Mbps) and high-distance (up to 30 km) transmissions.

EKI-2525M/2525S have industrial-grade designs, assuring high reliability and stability in harsh environments, making it a robust bridge between enterprise fiber-optic backbones and Ethernet devices. EKI-2525M/2525S includes a switch controller that can automatically sense transmission speeds. The RJ45 interface can also be autodetected, so MDI or MDI-X is automatically selected and a crossover cable is not required. All the Ethernet ports have memory buffers that support the store and forward mechanism, assuring all data is transmitted properly.

• Provides 4 x 10/100 Mbps Ethernet ports with RJ45 connector


• Provides 1 x 100 Mbps Multi-mode SC type fiber optic port (EKI-2525M)


• Provides 1 x 100 Mbps Multi-mode ST type fiber optic port (EKI-2525M-ST)


• Provides 1 x 100 Mbps Single-mode SC type fiber optic port (EKI-2525S)


• Supports full/half duplex flow control


• Supports MDI/MDI-X auto crossover


• Provides broadcast storm protection


• Provides redundant 12 ~ 48 VDC power input


• Provides flexible mounting: DIN-rail and Wall mount

Product Type: Ethernet Switch
Environmentally Friendly: Yes
Environmental Certification: WEEE
Product Series: EKI-2000
Brand Name: Advantech
Form Factor: DIN Rail Mountable
Manufacturer: Advantech Co., Ltd
Product Model: EKI-2525M
Product Name: 4-Port Ethernet Switch w/ 1-port 100FX Multi-Mode
Manufacturer Part Number: EKI-2525M-BE
Manufacturer Website Address: http://www.advantech.com
Limited Warranty: 5 Year
