24Port Mangd Switch 10/100/1G,Fx Sfp Ports Internal Ps Made Usa

Description :

ComNet CNGE24FX12TX12MS Ethernet Switch

The ComNet CNGE24FX12TX12MS[POE] has twelve 100/1000Base-FX SFP ports and twelve 10/100/1000Base-TX ports. Two of the SFP ports support 2.5 Gbps SFPs for high speed communication in bandwidth intensive applications. All SFP ports utilize ComNet SFP modules for fiber and connector type and distance. The IEEE802.3-compliant unit offers multiple Ethernet redundancy protocols (MSTP/RSTP/STP/ERPS (G.8032)) which protect your applications from network interruptions or temporary malfunctions by redirecting transmission within the network. The switch provides advanced IP-based management that can limit the maximum bandwidth for each connected IP device, allowing the user to adjust usage. The CNGE24FX12TX12MSPOE models provide twelve electrical ports supporting up to thirty watts of power. All PoE ports are IEEE 802.3at compliant. Each model is provided with redundant power inputs which can be either one mains voltage and two low voltage DC inputs or two low voltage DC inputs.

• 2 SFP ports support 2.5 Gbps SFP modules for high speed communication


• Supports IPV6 new internet protocol version


• Provided HTTPS/SSH protocol enhances network security


• Supports Device Binding security function


• IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic


• Supports SNMP v1/v2c/v3 & RMON & 802.1Q VLAN Network Management


• Supports ACL, 802.1x User Authentication for security


• Multiple notifications warn of unexpected events


• Fast Redundancy/Recovery - MSTP/RSTP/STP (IEEE802.1s/w/D) and ERPS (G.8032)


• Supports IP-based bandwidth management

Product Type: Ethernet Switch
Environmentally Friendly: Yes
Environmental Certification: WEEE
Compatible Rack Unit: 1U
Country Of Origin: United States
Product Series: CNGE24FX12TX12MS[POE]
Brand Name: ComNet
Form Factor: Desktop
Manufacturer: ACRE
Product Model: CNGE24FX12TX12MS
Product Name: CNGE24FX12TX12MS Ethernet Switch
Manufacturer Part Number: CNGE24FX12TX12MS
Manufacturer Website Address: http://www.acre-co.com
Packaged Quantity: 1
Limited Warranty: Lifetime
Weight (Approximate): 11 lb
